FAG BEARINGS Angular Contact Ball Bearing: 3306/5306, 2 Rows, 30°, Dbl Sealed, ABEC 3 - Double-Row Angular Contact Bearings
FAG BEARINGSDouble-Row Angular Contact Bearings

FAG BEARINGS Angular Contact Ball Bearing: 3306/5306, 2 Rows, 30°, Dbl Sealed, ABEC 3

The FAG BEARINGS Angular Contact Ball Bearing, model 3306/5306 (MPN 3306-BD-XL-2HRS-TVH-C3), is a double-row angular contact bearing with a 30° contact angle. It features double seals, ABEC 3 precision, and a 30 mm…

SKU 3G-OTH-104690

Brand
FAG BEARINGS
Item
Angular Contact Ball Bearing: 3306/5306, 2 Rows, 30°, Dbl Sealed, ABEC 3
Category
Double-Row Angular Contact Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

FAG BEARINGS
Manufacturer Part Number
3306-BD-XL-2HRS-TVH-C3
Type
30°, Dbl Sealed, ABEC 3
Bore
30 mm
Rows
2
Bearing Type
Single Bearing
Contact Bearing Type
Angular Contact
Matched Bearing Type
Not Matched/Single Bearing
System of Measurement
Metric
Bearing Industry Number
3306/5306
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

FAG BEARINGS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The FAG BEARINGS Angular Contact Ball Bearing, model 3306/5306 (MPN 3306-BD-XL-2HRS-TVH-C3), is a double-row angular contact bearing with a 30° contact angle. It features double seals, ABEC 3 precision, and a 30 mm bore, supplied as a single bearing (not matched). This metric bearing is designed for applications requiring radial and axial load support in a compact configuration.

Frequently Asked Questions

What is the FAG 3306-BD-XL-2HRS-TVH-C3 angular contact ball bearing used for?

This double-row angular contact ball bearing supports combined radial and axial loads in compact machinery. Common applications include gearboxes, pumps, compressors, and industrial fans where space is limited and reliable operation under moderate speeds is required.

What are the specifications of the FAG 3306/5306 bearing?

The FAG 3306-BD-XL-2HRS-TVH-C3 is a metric double-row angular contact bearing with a 30 mm bore, 30° contact angle, double seals, ABEC 3 precision, and C3 internal clearance. It is supplied as a single, not matched, bearing with industry number 3306/5306.

Where to buy FAG bearings in worldwide?

You can source the FAG 3306-BD-XL-2HRS-TVH-C3 bearing through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring your order arrives reliably at your facility.

How to select the correct FAG angular contact bearing for an application?

Select based on bore size (30 mm for this model), load type (radial and axial), contact angle (30° for moderate axial loads), sealing (double seals for contamination protection), and precision class (ABEC 3). Verify shaft and housing fits per FAG mounting guidelines for optimal performance.

Used in

Common applications for FAG BEARINGS
Electric motor repair — FAG double-row angular contact bearings (3306-BD-XL) for rotor support in medium-voltage motors
Machine tool spindles — FAG high-precision angular contact bearings (7210-B-XL-TVP-UA) for tandem duplex mounting in grinding spindles
Industrial pump assemblies — FAG self-aligning ball bearings (2203-2RS-TVH) for accommodating shaft misalignment in centrifugal pumps
Gearbox maintenance — FAG cylindrical roller bearings (NU207-E-XL-M1-C3) for high radial load and axial displacement in helical gear units
Compressor rebuilds — FAG angular contact bearings (7317-B-XL-TVP-UA) for thrust load handling in reciprocating compressors
Conveyor systems — FAG double-row angular contact bearings (3207-BD-XL-2Z) for sealed operation in belt conveyor idler rolls
