GE Miniature Circuit Breaker: THHQC, 60 A, 120/240V AC, Single Phase, 22kA at 120/240V AC - THQC & THHQC Series, Unit-Mount GE Miniature Circuit Breakers
GETHQC & THHQC Series, Unit-Mount GE Miniature Circuit Breakers

GE Miniature Circuit Breaker: THHQC, 60 A, 120/240V AC, Single Phase, 22kA at 120/240V AC

The GE THHQC is a unit-mount miniature circuit breaker from the THQC & THHQC Series, rated for 60 A, single phase, and 120/240V AC. It has a maximum AIR rating of 22kA at 120/240V AC and is designed for use with GE…

SKU 3G-OTH-22191

Brand
GE
Item
Miniature Circuit Breaker: THHQC, 60 A, 120/240V AC, Single Phase, 22kA at 120/240V AC
Category
THQC & THHQC Series, Unit-Mount GE Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
THHQC2160WL
Type
60 A, Single Phase, 22kA at 120/240V AC, Std
AC
120/240V
Amps
60 A
Phase
Single
For Use With
GE Panelboards
Max. AIR Rating
22kA at 120/240V AC
AC Voltage Rating
120/240V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE THHQC is a unit-mount miniature circuit breaker from the THQC & THHQC Series, rated for 60 A, single phase, and 120/240V AC. It has a maximum AIR rating of 22kA at 120/240V AC and is designed for use with GE panelboards (MPN THHQC2160WL).

Frequently Asked Questions

What is the GE THHQC2160WL miniature circuit breaker used for?

The GE THHQC2160WL is a unit-mount miniature circuit breaker designed to protect electrical circuits from overloads and short circuits. It is used in residential and commercial applications, specifically with GE panelboards, for single-phase systems at 120/240V AC.

What are the specifications of the GE THHQC2160WL circuit breaker?

The GE THHQC2160WL is rated for 60 A, single phase, 120/240V AC, with a maximum AIR rating of 22kA at 120/240V AC. It is part of the THQC & THHQC Series and is designed for use with GE panelboards.

Where to buy the GE THHQC2160WL circuit breaker worldwide?

You can source the GE THHQC2160WL miniature circuit breaker through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring reliable supply for your project needs.

How to install the GE THHQC2160WL miniature circuit breaker?

Install the GE THHQC2160WL by ensuring the panelboard is de-energized, then snap the unit-mount breaker into the designated slot. Connect the line and load wires to the appropriate terminals, torque to manufacturer specifications, and verify proper seating before restoring power.
