GE Molded Case Circuit Breaker: 20 A Amps, 18kA at 120/240/277/480V AC, Fixed - TED-, TEHD-Frame GE Molded Case Circuit Breakers
GETED-, TEHD-Frame GE Molded Case Circuit Breakers

GE Molded Case Circuit Breaker: 20 A Amps, 18kA at 120/240/277/480V AC, Fixed

The GE Molded Case Circuit Breaker (SKU 6CPT7) is a TED- and TEHD-frame molded case circuit breaker rated for 20 A. It features a fixed instantaneous trip, a maximum AIR rating of 18kA at 120/240/277/480V AC, and ABC…

SKU 3G-OTH-21427

Brand
GE
Item
Molded Case Circuit Breaker: 20 A Amps, 18kA at 120/240/277/480V AC, Fixed
Category
TED-, TEHD-Frame GE Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GE
Manufacturer Part Number
TED136020WL
Series
TED
Type
18kA at 120/240/277/480V AC, Fixed, Line/Load Lug, ABC
Max. AIR Rating
18kA at 120/240/277/480V AC
Phase Connection
ABC
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GE Molded Case Circuit Breaker (SKU 6CPT7) is a TED- and TEHD-frame molded case circuit breaker rated for 20 A. It features a fixed instantaneous trip, a maximum AIR rating of 18kA at 120/240/277/480V AC, and ABC phase connection with line/load lug terminals. This unit is identified by manufacturer part number TED136020WL.

Frequently Asked Questions

What is the GE TED136020WL molded case circuit breaker used for?

The GE TED136020WL is a 20 A molded case circuit breaker used for overcurrent protection in commercial and industrial electrical distribution panels. It is suitable for branch circuits and feeder protection in systems up to 480V AC, with a maximum AIR rating of 18kA.

What are the specifications of the GE TED136020WL circuit breaker?

The GE TED136020WL is a TED-series molded case circuit breaker rated at 20 A with a fixed instantaneous trip. It has a maximum AIR rating of 18kA at 120/240/277/480V AC, ABC phase connection, and line/load lug terminals. The manufacturer part number is TED136020WL.

Where to buy the GE TED136020WL circuit breaker worldwide?

You can source the GE TED136020WL circuit breaker through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the GE TED136020WL molded case circuit breaker?

Install the GE TED136020WL by ensuring the panel is de-energized, then mount the breaker onto the DIN rail or panel base. Connect line and load conductors to the lug terminals, torque to manufacturer specifications, and verify the fixed instantaneous trip setting is correct for your application.
