GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC - FDA-Compliant EODD Pumps
GRACOFDA-Compliant EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC

The GRACO Electric Diaphragm Pump (SKU 411VT8, MPN HE30-1209) is an FDA-compliant EODD pump with a stainless steel body, three-phase 380-480V AC operation, 1-inch ports, and a 29 ft maximum head. It features a 316 SS…

SKU 3G-OTH-89918

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC
Category
FDA-Compliant EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE30-1209
Type
Three Phase, 1 in
AC
380-480V
Max. Head
29 ft
Seat Material
316 SS
Nameplate Voltage
380-480V AC
Surface Roughness
32 Ra
Check Valve Material
FKM
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump (SKU 411VT8, MPN HE30-1209) is an FDA-compliant EODD pump with a stainless steel body, three-phase 380-480V AC operation, 1-inch ports, and a 29 ft maximum head. It features a 316 SS seat material, FKM check valve material, and a 32 Ra surface roughness.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE30-1209 used for?

The GRACO HE30-1209 is an FDA-compliant EODD pump designed for sanitary transfer of fluids in food, dairy, and pharmaceutical applications. Its stainless steel body and 32 Ra surface finish meet hygiene standards, while the FKM check valves handle aggressive media.

What are the specifications of the GRACO HE30-1209 pump?

The GRACO HE30-1209 is a three-phase electric diaphragm pump with 380-480V AC input, 1-inch ports, and a 29 ft maximum head. It features a 316 SS seat material, FKM check valves, and a 32 Ra surface roughness for FDA compliance.

Where to buy the GRACO HE30-1209 pump worldwide?

3G Electric supplies the GRACO HE30-1209 pump worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this FDA-compliant EODD pump.

How to select the right GRACO electric diaphragm pump?

Select based on fluid compatibility, required head, and power supply. The HE30-1209 suits 380-480V AC three-phase systems, with 316 SS seats and FKM seals for corrosive or sanitary fluids. Confirm port size (1 in) and surface finish (32 Ra) meet your application standards.

Used in

Common applications for GRACO
Food and beverage processing — Graco FDA-compliant electric diaphragm pumps (e.g., HE120-1200) for sanitary fluid transfer
Pharmaceutical manufacturing — Graco USP Class VI-compliant AODD pumps (e.g., SP4F.0006) for sterile liquid handling
Chemical processing — Graco aluminum or stainless steel diaphragm pumps (e.g., TE120-1100) for corrosive fluid transfer
Automotive lubrication — Graco grease pump control replacement kits (e.g., 18F169) for maintenance of lubrication systems
Paint and coating application — Graco discharge spouts (e.g., 255858) for precise fluid dispensing in finishing lines
Water and wastewater treatment — Graco electric diaphragm pumps (e.g., HE120-1503) for sludge and chemical dosing
