GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC - FDA-Compliant EODD Pumps
GRACOFDA-Compliant EODD Pumps

GRACO Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC

The GRACO Electric Diaphragm Pump with Stainless Steel Body (MPN HE30-1204) is an FDA-compliant EODD pump featuring a 1-inch port and 29 ft max. head. It operates on three-phase 380-480V AC power, with a 316 SS seat…

SKU 3G-OTH-91125

Brand
GRACO
Item
Electric Diaphragm Pump: Stainless Steel Body, Three Phase, 380-480V AC
Category
FDA-Compliant EODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

GRACO
Manufacturer Part Number
HE30-1204
Type
Three Phase, 1 in
AC
380-480V
Max. Head
29 ft
Seat Material
316 SS
Nameplate Voltage
380-480V AC
Surface Roughness
32 Ra
Check Valve Material
Santoprene
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

GRACO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The GRACO Electric Diaphragm Pump with Stainless Steel Body (MPN HE30-1204) is an FDA-compliant EODD pump featuring a 1-inch port and 29 ft max. head. It operates on three-phase 380-480V AC power, with a 316 SS seat material, Santoprene check valve material, and a surface roughness of 32 Ra.

Frequently Asked Questions

What is the GRACO Electric Diaphragm Pump HE30-1204 used for?

The GRACO Electric Diaphragm Pump HE30-1204 is an FDA-compliant EODD pump designed for sanitary transfer of fluids in food, pharmaceutical, and chemical processing. Its 316 SS seat and Santoprene check valves handle aggressive media while maintaining 32 Ra surface finish for cleanability.

What are the specifications of the GRACO HE30-1204 pump?

The GRACO HE30-1204 is a three-phase electric diaphragm pump with a stainless steel body, 1-inch port, and 29 ft max. head. It operates on 380-480V AC, features a 316 SS seat, Santoprene check valves, and 32 Ra surface roughness. It is FDA-compliant for sanitary applications.

Where to buy the GRACO HE30-1204 pump worldwide?

You can source the GRACO HE30-1204 pump through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this FDA-compliant EODD pump.

How to select the right GRACO electric diaphragm pump?

Select based on fluid compatibility, pressure, and flow needs. For the HE30-1204, ensure your power supply matches 380-480V AC three-phase. Confirm media is compatible with 316 SS seats and Santoprene valves. For FDA-grade transfer, verify 32 Ra surface finish meets your hygiene requirements.
