HAM-LET Ultra High Purity Diaphragm Valve: 3/4 in, 316L Stainless Steel - Ultra-High-Purity Manual Diaphragm Valves
HAM-LETUltra-High-Purity Manual Diaphragm Valves

HAM-LET Ultra High Purity Diaphragm Valve: 3/4 in, 316L Stainless Steel

The HAM-LET Ultra High Purity Diaphragm Valve (SKU 884FK3) is a 3/4 in ultra-high-purity manual diaphragm valve constructed from 316L stainless steel. It features a Chromium Cobalt Nickel diaphragm and is rated for a…

SKU 3G-OTH-446404

Brand
HAM-LET
Item
Ultra High Purity Diaphragm Valve: 3/4 in, 316L Stainless Steel
Category
Ultra-High-Purity Manual Diaphragm Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAM-LET
Manufacturer Part Number
2LDS12R-FV
Standards
SEMI F20-0305
Stainless Steel
316L
Diaphragm Material
Chromium Cobalt Nickel
Max Pressure (CWP)
225 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAM-LET Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAM-LET Ultra High Purity Diaphragm Valve (SKU 884FK3) is a 3/4 in ultra-high-purity manual diaphragm valve constructed from 316L stainless steel. It features a Chromium Cobalt Nickel diaphragm and is rated for a maximum pressure of 225 psi (CWP). This valve complies with SEMI F20-0305 standards, ensuring suitability for demanding high-purity applications.

Frequently Asked Questions

What is the HAM-LET Ultra High Purity Diaphragm Valve used for?

This valve is designed for ultra-high-purity gas and chemical handling in semiconductor manufacturing, pharmaceutical processing, and other critical clean environments. Its 316L stainless steel body and Chromium Cobalt Nickel diaphragm prevent contamination, meeting SEMI F20-0305 standards for high-purity applications.

What are the specifications of the HAM-LET 2LDS12R-FV diaphragm valve?

The HAM-LET 2LDS12R-FV is a 3/4 in manual diaphragm valve with a 316L stainless steel body, Chromium Cobalt Nickel diaphragm, and a maximum pressure rating of 225 psi (CWP). It complies with SEMI F20-0305 standards, ensuring reliable performance in ultra-high-purity systems.

Where to buy HAM-LET Ultra High Purity Diaphragm Valves worldwide?

3G Electric supplies HAM-LET Ultra High Purity Diaphragm Valves worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on the 2LDS12R-FV or other HAM-LET models.

How to install a HAM-LET ultra-high-purity diaphragm valve?

Install the valve in a clean environment using appropriate orbital welding or compression fittings for 316L stainless steel tubing. Ensure the diaphragm is not overtightened to avoid damage. Follow SEMI F20-0305 guidelines for purging and leak testing to maintain system purity.
