HAM-LET Ultra High Purity Diaphragm Valve: 1/4 in, 316L Stainless Steel - Ultra-High-Purity Manual Diaphragm Valves
HAM-LETUltra-High-Purity Manual Diaphragm Valves

HAM-LET Ultra High Purity Diaphragm Valve: 1/4 in, 316L Stainless Steel

The HAM-LET Ultra High Purity Diaphragm Valve (1/4 in) is an ultra-high-purity manual diaphragm valve from HAM-LET, constructed from 316L Stainless Steel. It features a Chromium Cobalt Nickel diaphragm and complies…

SKU 3G-OTH-446397

Brand
HAM-LET
Item
Ultra High Purity Diaphragm Valve: 1/4 in, 316L Stainless Steel
Category
Ultra-High-Purity Manual Diaphragm Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAM-LET
Manufacturer Part Number
2LDS4R-BV
Standards
SEMI F20-0305
Stainless Steel
316L
Diaphragm Material
Chromium Cobalt Nickel
Max Pressure (CWP)
225 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAM-LET Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAM-LET Ultra High Purity Diaphragm Valve (1/4 in) is an ultra-high-purity manual diaphragm valve from HAM-LET, constructed from 316L Stainless Steel. It features a Chromium Cobalt Nickel diaphragm and complies with SEMI F20-0305 standards, with a maximum pressure rating of 225 psi (CWP).

Frequently Asked Questions

What is the HAM-LET Ultra High Purity Diaphragm Valve used for?

The HAM-LET Ultra High Purity Diaphragm Valve is used in semiconductor and high-purity gas delivery systems where contamination control is critical. It isolates and regulates ultra-pure fluids in applications requiring compliance with SEMI F20-0305 standards, such as chemical and specialty gas handling.

What are the specifications of the HAM-LET Ultra High Purity Diaphragm Valve?

This valve has a 1/4 in connection, 316L Stainless Steel body, and a Chromium Cobalt Nickel diaphragm. It is rated for 225 psi maximum pressure (CWP) and complies with SEMI F20-0305. The manufacturer part number is 2LDS4R-BV, and it is a manual ultra-high-purity diaphragm valve from HAM-LET.

Where to buy the HAM-LET Ultra High Purity Diaphragm Valve worldwide?

3G Electric supplies the HAM-LET Ultra High Purity Diaphragm Valve worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this valve with part number 2LDS4R-BV for your high-purity application.

How to install the HAM-LET Ultra High Purity Diaphragm Valve?

Install the HAM-LET valve in a clean environment to maintain purity. Use appropriate fittings for 1/4 in connections and ensure the system is depressurized before installation. Follow SEMI F20-0305 guidelines for ultra-high-purity systems. Torque connections to manufacturer specifications to avoid damaging the Chromium Cobalt Nickel diaphragm.
