HAYWARD Foot Valve Screen: CPVC, 2 in Pipe Size, CPVC, Foot Valve Screen, Ball Check Valve - Foot Valve Screens
HAYWARDFoot Valve Screens

HAYWARD Foot Valve Screen: CPVC, 2 in Pipe Size, CPVC, Foot Valve Screen, Ball Check Valve

The HAYWARD Foot Valve Screen is a CPVC foot valve screen designed for use with 2-inch pipe sizes. This model, part number FV20200SA, is compatible with the TC20200ST(X) manufacturer model and Grainger part number…

SKU 3G-OTH-435890

Brand
HAYWARD
Item
Foot Valve Screen: CPVC, 2 in Pipe Size, CPVC, Foot Valve Screen, Ball Check Valve
Category
Foot Valve Screens
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAYWARD
Manufacturer Part Number
FV20200SA
Type
CPVC, Foot Valve Screen, Ball Check Valve, 5AAV0
Pipe Size
2 in
Strainer Material
CPVC
Compatible with Mfr. Model No.
TC20200ST(X)
Compatible with Grainger Part No.
5AAV0
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAYWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAYWARD Foot Valve Screen is a CPVC foot valve screen designed for use with 2-inch pipe sizes. This model, part number FV20200SA, is compatible with the TC20200ST(X) manufacturer model and Grainger part number 5AAV0. It features a CPVC strainer material and functions as a ball check valve screen.

Frequently Asked Questions

What is a HAYWARD foot valve screen used for?

A HAYWARD foot valve screen is used to protect pumps and piping systems from debris in water or chemical applications. It fits 2-inch CPVC pipes and includes a ball check valve to prevent backflow, making it suitable for industrial filtration and fluid handling systems.

What are the specifications of the HAYWARD foot valve screen FV20200SA?

The HAYWARD foot valve screen model FV20200SA has a CPVC strainer material and is designed for 2-inch pipe size. It is compatible with manufacturer model TC20200ST(X) and Grainger part number 5AAV0. This ball check valve screen is built for corrosion resistance in demanding environments.

Where to buy HAYWARD foot valve screens worldwide?

You can source HAYWARD foot valve screens worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead times on the FV20200SA model.

How to install a HAYWARD CPVC foot valve screen?

To install a HAYWARD CPVC foot valve screen, ensure the 2-inch pipe is clean and apply CPVC-compatible primer and cement to both the pipe and valve socket. Insert the pipe fully, twist slightly, and hold for a few seconds. Allow proper cure time before pressurizing the system.
