HAYWARD Foot Valve Screen: CPVC, 3 in Pipe Size, CPVC, Foot Valve Screen, Ball Check Valve - Foot Valve Screens
HAYWARDFoot Valve Screens

HAYWARD Foot Valve Screen: CPVC, 3 in Pipe Size, CPVC, Foot Valve Screen, Ball Check Valve

The HAYWARD Foot Valve Screen is a CPVC foot valve screen designed for use with the TC2300F(X) ball check valve. This model, MPN FV20300SA, features a 3-inch pipe size and is constructed from CPVC strainer material…

SKU 3G-OTH-435892

Brand
HAYWARD
Item
Foot Valve Screen: CPVC, 3 in Pipe Size, CPVC, Foot Valve Screen, Ball Check Valve
Category
Foot Valve Screens
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HAYWARD
Manufacturer Part Number
FV20300SA
Type
CPVC, Foot Valve Screen, Ball Check Valve, 5AAV4
Pipe Size
3 in
Strainer Material
CPVC
Compatible with Mfr. Model No.
TC2300F(X)
Compatible with Grainger Part No.
5AAV4
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HAYWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HAYWARD Foot Valve Screen is a CPVC foot valve screen designed for use with the TC2300F(X) ball check valve. This model, MPN FV20300SA, features a 3-inch pipe size and is constructed from CPVC strainer material. It is compatible with Grainger Part No. 5AAV4.

Frequently Asked Questions

What is the HAYWARD Foot Valve Screen used for?

The HAYWARD Foot Valve Screen is used to protect a ball check valve from debris in industrial piping systems. It is designed for use with the TC2300F(X) valve and is suitable for applications requiring CPVC corrosion resistance, such as chemical processing and water treatment.

What are the specifications of the HAYWARD Foot Valve Screen FV20300SA?

The HAYWARD Foot Valve Screen model FV20300SA has a 3 in pipe size and is made of CPVC strainer material. It is compatible with the TC2300F(X) ball check valve and Grainger Part No. 5AAV4. The CPVC construction provides chemical resistance for demanding fluid handling environments.

Where to buy the HAYWARD Foot Valve Screen worldwide?

You can source the HAYWARD Foot Valve Screen FV20300SA through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this CPVC foot valve screen.

How to install the HAYWARD Foot Valve Screen?

Install the HAYWARD Foot Valve Screen by threading it onto the inlet of the TC2300F(X) ball check valve. Ensure the CPVC screen is clean and free of debris before installation. Use PTFE tape on threads for a secure seal. Follow standard piping practices for CPVC components to avoid overtightening.
