HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #2-56 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #2-56 Thread Size

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #2-56 Thread Size, 1,000 PK (MPN 3585-02CNW086S). This 18-8 metal insert features a Dry Film Lubricant finish, Right Hand thread direction, Coarse thread…

SKU 3G-OTH-528957

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, #2-56 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
3585-02CNW086S
Type
Screw-Locking, #2-56 Thread Size, 1,000 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Type
Coarse
STI Tap Size
#2-56
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #2-56 Thread Size, 1,000 PK (MPN 3585-02CNW086S). This 18-8 metal insert features a Dry Film Lubricant finish, Right Hand thread direction, Coarse thread type, and STI Tap Size #2-56, with a Tensile Strength of 200,000 to 250,000 psi in the Inch system of measurement.

Frequently Asked Questions

What is a HELI-COIL screw-locking tanged helical insert used for?

A HELI-COIL screw-locking tanged helical insert repairs or reinforces threads in metal, providing a strong, wear-resistant internal thread. The screw-locking feature resists vibration loosening. It is commonly used in automotive, aerospace, and industrial maintenance applications where thread integrity is critical.

What are the specifications of the HELI-COIL 3585-02CNW086S insert?

This HELI-COIL insert has a #2-56 thread size, coarse thread type, and right-hand direction. It is made of 18-8 stainless steel with a dry film lubricant finish, offering a tensile strength of 200,000 to 250,000 psi. The STI tap size is #2-56, and it comes in a 1,000-piece pack.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the HELI-COIL 3585-02CNW086S or other thread repair inserts for your application.

How to install a HELI-COIL tanged helical insert?

To install a HELI-COIL tanged insert, drill out the damaged thread to the specified size, tap the hole using the correct STI tap, then insert the coil using a tang drive tool. After installation, break off the tang. Always follow the manufacturer's instructions for proper thread engagement and torque.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
