HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-28 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-28 Thread Size, Plain

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with a 1/4"-28 fine thread, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, is compatible with…

SKU 3G-OTH-529064

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-28 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
3591-4CN375S
Type
Screw-Locking, Plain, 1,000 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Size
1/4"-28
Thread Type
Fine
STI Tap Size
1/4"-28
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with a 1/4"-28 fine thread, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, is compatible with metal, and comes in a 1,000-piece pack (MPN 3591-4CN375S).

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. This screw-locking, tanged tang-style insert with 1/4"-28 fine thread provides strong, wear-resistant threads in aluminum, cast iron, or steel components, preventing thread stripping under high-stress applications.

What are the specifications of the HELI-COIL 3591-4CN375S insert?

This HELI-COIL insert has a 1/4"-28 fine thread, right-hand direction, 18-8 material grade, and plain finish. It offers tensile strength of 200,000 to 250,000 psi, requires an STI tap size of 1/4"-28, and comes in a 1,000-piece pack (MPN 3591-4CN375S).

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this 1/4"-28 screw-locking insert (MPN 3591-4CN375S) to your facility, ensuring compliance with international shipping requirements.

How to install a HELI-COIL tanged tang-style insert?

To install a HELI-COIL tanged insert, drill to the specified size, tap with the correct STI tap (1/4"-28 for this insert), then use a tang-style installation tool to wind the insert into the tapped hole. After installation, break off the tang with a punch for a permanent, screw-locking thread repair.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
