HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-28 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-28 Thread Size

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert in a 1,000-piece pack, featuring a 1/4"-28 fine thread, right-hand direction, and 18-8 material grade. It offers a tensile strength of 200,000…

SKU 3G-OTH-529032

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-28 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
3591-4CNW375S
Type
Screw-Locking, 1,000 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Size
1/4"-28
Thread Type
Fine
STI Tap Size
1/4"-28
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert in a 1,000-piece pack, featuring a 1/4"-28 fine thread, right-hand direction, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, with a dry film lubricant finish, and is compatible with metal substrates.

Frequently Asked Questions

What is a HELI-COIL screw-locking helical insert used for?

A HELI-COIL screw-locking helical insert repairs or reinforces tapped threads in metal, providing a strong, wear-resistant thread. The screw-locking feature resists vibration loosening. 3G Electric supplies these inserts for industrial maintenance and production across machining, power transmission, and other departments.

What are the specifications of the HELI-COIL 3591-4CNW375S insert?

This HELI-COIL insert has a 1/4"-28 fine thread, right-hand direction, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, with a dry film lubricant finish. The pack contains 1,000 pieces, and the STI tap size is 1/4"-28.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide, handling logistics, customs, and delivery to your facility. As a global industrial solutions provider, we source genuine parts like the 3591-4CNW375S across 14 departments, including machining and electrical, ensuring you get the right product for your application.

How to install a HELI-COIL tanged tang style insert?

Install a HELI-COIL tanged insert by drilling out the damaged thread, tapping with the specified STI tap (1/4"-28), then winding the insert into the hole using a tang drive tool. After installation, break off the tang. 3G Electric can advise on tooling and best practices for metal substrates.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
