HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with M6-1.00 coarse thread size, right-hand direction, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi…

SKU 3G-OTH-529022

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
4184-6CNW090S
Type
Screw-Locking, M6-1.00 Thread Size, 1,000 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Type
Coarse
STI Tap Size
M6-1.00
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with M6-1.00 coarse thread size, right-hand direction, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, features a dry film lubricant finish, and is compatible with metal substrates. Supplied in a 1,000-piece pack (MPN 4184-6CNW090S), this metric insert is designed for use with an M6-1.00 STI tap.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threaded holes in metal. This screw-locking, tanged tang-style M6-1.00 insert provides strong, wear-resistant threads in soft materials like aluminum or cast iron, preventing thread stripping under high loads.

What are the specifications of the HELI-COIL 4184-6CNW090S insert?

This HELI-COIL insert has an M6-1.00 coarse thread, right-hand direction, 18-8 material grade, and tensile strength of 200,000 to 250,000 psi. It features a dry film lubricant finish, is compatible with metal, and requires an M6-1.00 STI tap for installation.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the M6-1.00 screw-locking insert (MPN 4184-6CNW090S) for your application.

How to install a HELI-COIL tanged tang-style insert?

To install a HELI-COIL tanged insert, drill out the damaged thread to the specified size, tap the hole using an M6-1.00 STI tap, then wind the insert into the hole using a tang drive tool. After installation, break off the tang with a punch for a permanent, screw-locking thread.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
