HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-20 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-20 Thread Size

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert with a 1/4"-20 coarse thread, 18-8 material grade, and dry film lubricant finish. It offers a tensile strength of 200,000 to 250,000 psi, is…

SKU 3G-OTH-528952

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 1/4"-20 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A3585-4CNW250
Type
Screw-Locking, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Size
1/4"-20
Thread Type
Coarse
STI Tap Size
1/4"-20
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert with a 1/4"-20 coarse thread, 18-8 material grade, and dry film lubricant finish. It offers a tensile strength of 200,000 to 250,000 psi, is compatible with metal, and comes in a 100-piece pack (MPN A3585-4CNW250).

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. It provides a strong, wear-resistant internal thread for fasteners, especially in soft materials like aluminum. The screw-locking version resists vibration loosening. 3G Electric supplies this insert for industrial maintenance and production applications worldwide.

What are the specifications of the HELI-COIL A3585-4CNW250?

This HELI-COIL insert has a 1/4"-20 coarse thread, 18-8 material grade, and a tensile strength of 200,000 to 250,000 psi. It is a tanged tang style, screw-locking type with dry film lubricant finish, right-hand thread, and comes in a 100-piece pack (MPN A3585-4CNW250).

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts to customers worldwide. We handle full logistics and customs clearance for international orders. Contact us to source the A3585-4CNW250 or other thread repair inserts for your industrial needs.

How to install a HELI-COIL tanged helical insert?

To install a HELI-COIL tanged insert, drill out the damaged thread to the specified STI tap size (1/4"-20), tap the hole, then use a tang-style installation tool to wind the insert into place. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
