HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-18 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-18 Thread Size

3G Electric supplies the HELI-COIL Helical Insert: Tanged Tang Style, a screw-locking tanged helical insert (SKU 4GDJ9, MPN A3585-5CNW625) with a 5/16"-18 coarse thread, 18-8 material grade, and tensile strength of…

SKU 3G-OTH-528892

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-18 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A3585-5CNW625
Type
Screw-Locking, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Size
5/16"-18
Thread Type
Coarse
STI Tap Size
5/16"-18
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

3G Electric supplies the HELI-COIL Helical Insert: Tanged Tang Style, a screw-locking tanged helical insert (SKU 4GDJ9, MPN A3585-5CNW625) with a 5/16"-18 coarse thread, 18-8 material grade, and tensile strength of 200,000 to 250,000 psi. This 100-pack insert features a dry film lubricant finish and is compatible with metal, backed by our specialist expertise in sourcing across 14 industrial departments.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces tapped threads in metal. The screw-locking tanged tang style provides vibration resistance, making it ideal for automotive, aerospace, and industrial maintenance applications where thread integrity is critical.

What are the specifications of the HELI-COIL A3585-5CNW625 insert?

This HELI-COIL insert has a 5/16"-18 coarse thread, 18-8 material grade, and tensile strength of 200,000 to 250,000 psi. It is right-hand threaded, screw-locking, tanged tang style, with a dry film lubricant finish, and comes in a 100-pack.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle logistics, customs, and delivery to your location. Contact us to order the A3585-5CNW625 or other thread repair inserts.

How to install a tanged helical insert?

Install a tanged helical insert by tapping the hole with the correct STI tap (5/16"-18 for this insert), then using a tang installation tool to wind the insert into the hole. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
