HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-24 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-24 Thread Size

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert designed for metal applications. This plain-finish, inch-system insert features a 5/16"-24 fine thread, right-hand direction, and a tensile…

SKU 3G-OTH-529087

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 5/16"-24 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A3591-5EN312
Type
Screw-Locking, Plain, 100 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Size
5/16"-24
Thread Type
Fine
STI Tap Size
5/16"-24
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
Nitronic 60
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert designed for metal applications. This plain-finish, inch-system insert features a 5/16"-24 fine thread, right-hand direction, and a tensile strength of 200,000 psi, made from Nitronic 60 material (MPN A3591-5EN312). Supplied in a 100-piece pack, it is compatible with a 5/16"-24 STI tap size.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. This screw-locking, tanged tang-style insert with 5/16"-24 fine thread provides strong, wear-resistant threads in applications like automotive, aerospace, and industrial machinery, preventing thread stripping and extending component life.

What are the specifications of the HELI-COIL A3591-5EN312 insert?

This HELI-COIL insert has a 5/16"-24 fine thread, right-hand direction, and a tensile strength of 200,000 psi. It is made from Nitronic 60 material, has a plain finish, and requires a 5/16"-24 STI tap. Supplied in a 100-piece pack, it is compatible with metal substrates.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver the A3591-5EN312 screw-locking insert to your facility. Contact us for availability and lead time on this 100-pack of 5/16"-24 inserts.

How to install a HELI-COIL tanged helical insert?

To install a HELI-COIL tanged insert, drill the hole to the specified size, tap it with the correct STI tap (5/16"-24 for this insert), then use a tang-style installation tool to wind the insert into the tapped hole. After installation, break off the tang with a punch for a permanent thread repair.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates

HELI-COIL Products

3G Electric supplies HELI-COIL screw-locking tanged helical inserts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
