HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain, 100 PK (MPN A4184-6CN060). This 18-8 stainless steel insert has a tensile strength of 200,000 to 250,000 psi, requires a 6.25mm…

SKU 3G-OTH-528984

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A4184-6CN060
Type
Screw-Locking, M6-1.00 Thread Size, Plain, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
M6-1.00
Drill Bit Size
6.25mm
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain, 100 PK (MPN A4184-6CN060). This 18-8 stainless steel insert has a tensile strength of 200,000 to 250,000 psi, requires a 6.25mm drill bit and M6-1.00 STI tap, and is designed for right-hand threads in metal.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. This M6-1.00 screw-locking tanged style provides a strong, wear-resistant thread for right-hand fasteners, ideal for automotive, aerospace, and industrial maintenance applications.

What are the specifications of the HELI-COIL A4184-6CN060 insert?

This HELI-COIL insert has an M6-1.00 thread size, 18-8 stainless steel material, tensile strength of 200,000 to 250,000 psi, and requires a 6.25mm drill bit with an M6-1.00 STI tap. It is plain finish, right-hand thread, and comes in a 100-pack.

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this M6-1.00 screw-locking insert to your facility, ensuring you get the right thread repair solution.

How to install a HELI-COIL tanged helical insert?

To install, drill a 6.25mm hole, tap it with an M6-1.00 STI tap, then use a tang installation tool to wind the insert into the thread. Break off the tang after installation. Ensure the hole is clean and lubricated for proper seating.
