HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain, 100 PK (MPN A4184-6CN090). This 18-8 stainless steel insert has a tensile strength of 200,000 to 250,000 psi, requires a 6.25mm…

SKU 3G-OTH-528940

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A4184-6CN090
Type
Screw-Locking, M6-1.00 Thread Size, Plain, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
M6-1.00
Drill Bit Size
6.25mm
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M6-1.00 Thread Size, Plain, 100 PK (MPN A4184-6CN090). This 18-8 stainless steel insert has a tensile strength of 200,000 to 250,000 psi, requires a 6.25mm drill bit and M6-1.00 STI tap, and is compatible with metal substrates.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. This screw-locking, tanged tang style M6-1.00 insert provides a strong, wear-resistant thread in aluminum, cast iron, or steel. It is ideal for automotive, aerospace, and industrial maintenance applications where stripped threads need a durable, permanent fix.

What are the specifications of the HELI-COIL A4184-6CN090 insert?

This HELI-COIL insert has an M6-1.00 thread size, 18-8 stainless steel construction, and a tensile strength of 200,000 to 250,000 psi. It requires a 6.25mm drill bit and an M6-1.00 STI tap. The plain finish, right-hand thread, and screw-locking design suit metal substrates. Pack of 100.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on the A4184-6CN090 M6-1.00 screw-locking insert. We source genuine HELI-COIL products for industrial maintenance.

How to install a HELI-COIL screw-locking insert?

Drill the stripped hole to 6.25mm, then tap it with an M6-1.00 STI tap. Clean the threads, then use a HELI-COIL installation tool to wind the insert into the hole. Break off the tang after installation. The screw-locking feature grips the bolt to resist vibration. Follow standard thread repair practices for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates

HELI-COIL Products

3G Electric supplies HELI-COIL screw-locking tanged helical inserts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
