KIPP Locating Pin Bushing: 6 mm Inside Dia, 10 mm Outside Dia, 12 mm Overall Lg - Locating Pin Bushings
KIPPLocating Pin Bushings

KIPP Locating Pin Bushing: 6 mm Inside Dia, 10 mm Outside Dia, 12 mm Overall Lg

The KIPP Locating Pin Bushing (MPN K1095.0610) is a steel bushing with a Rockwell C60 hardness, featuring a 6 mm inside diameter, 10 mm outside diameter, and 12 mm overall length. This locating pin bushing is…

SKU 3G-OTH-179770

Brand
KIPP
Item
Locating Pin Bushing: 6 mm Inside Dia, 10 mm Outside Dia, 12 mm Overall Lg
Category
Locating Pin Bushings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

KIPP
Manufacturer Part Number
K1095.0610
Type
Steel, Rockwell C60
Overall Lg
12 mm
Outside Dia
10 mm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

KIPP Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The KIPP Locating Pin Bushing (MPN K1095.0610) is a steel bushing with a Rockwell C60 hardness, featuring a 6 mm inside diameter, 10 mm outside diameter, and 12 mm overall length. This locating pin bushing is designed for precise alignment and positioning in industrial fixturing and tooling applications.

Frequently Asked Questions

What is KIPP locating pin bushing used for?

KIPP locating pin bushings are used in jigs, fixtures, and assembly tooling to guide locating pins precisely. They ensure repeatable alignment of workpieces during machining, welding, or inspection operations in industrial manufacturing environments.

What are the specifications of KIPP locating pin bushing K1095.0610?

The KIPP locating pin bushing model K1095.0610 has a 6 mm inside diameter, 10 mm outside diameter, and 12 mm overall length. It is made of steel with a Rockwell C60 hardness rating, providing wear resistance for repeated pin insertion.

Where to buy KIPP locating pin bushings worldwide?

KIPP locating pin bushings are available to order through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive genuine KIPP components for your tooling needs.

How to install a KIPP locating pin bushing?

To install a KIPP locating pin bushing, press it into a reamed or drilled hole in your fixture plate using an arbor press. Ensure the bushing is seated flush or slightly below the surface. Use a slip-fit locating pin for smooth insertion and removal during operation.

Used in

Common applications for KIPP
Jig and fixture construction — KIPP indexing plungers (e.g., SKU 53EC55) for repeatable workpiece positioning
Assembly line tooling — KIPP threaded grippers with flat pads (e.g., SKU 801Y95) for clamping components
Machine tool alignment — KIPP tapered-head locating pins (e.g., SKU 801XY4) for precise part registration
Sanitary processing equipment — KIPP hygienic sockets (e.g., SKU 802KU2) for tooling in food-grade environments
Abrasive material handling — KIPP diamond-faced inserts (e.g., SKU 801XH6) for gripping in dusty or gritty conditions
Fixture leveling and support — KIPP positioning feet with flat faces (e.g., SKU 615V08) for stable machine setup
