KIPP Locating Pin Bushing: 10 mm Inside Dia, 15 mm Outside Dia, 26 mm Overall Lg - Locating Pin Bushings
KIPPLocating Pin Bushings

KIPP Locating Pin Bushing: 10 mm Inside Dia, 15 mm Outside Dia, 26 mm Overall Lg

SKU 3G-OTH-179766

Brand
KIPP
Item
Locating Pin Bushing: 10 mm Inside Dia, 15 mm Outside Dia, 26 mm Overall Lg
Category
Locating Pin Bushings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

KIPP
Manufacturer Part Number
K1095.1014
Type
Steel
Overall Lg
26 mm
Outside Dia
15 mm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

KIPP Products
3G Electric (S) Pte. Ltd. — Singapore

Frequently Asked Questions

What is a KIPP locating pin bushing used for?

A KIPP locating pin bushing is used in jigs, fixtures, and tooling to guide and align locating pins precisely during workpiece positioning. It ensures repeatable accuracy in machining, assembly, and inspection applications across industrial manufacturing.

What are the specifications of the KIPP K1095.1014 locating pin bushing?

The KIPP K1095.1014 locating pin bushing has a 10 mm inside diameter, 15 mm outside diameter, and 26 mm overall length. It is made of steel and is designed for durable, high-precision alignment in industrial tooling and fixturing.

Where to buy KIPP locating pin bushings worldwide?

3G Electric supplies KIPP locating pin bushings worldwide, handling full logistics and customs clearance for global delivery. As a sourcing partner, we provide genuine KIPP components like the K1095.1014 to support your industrial tooling needs.

How to install a KIPP locating pin bushing?

Press-fit the KIPP locating pin bushing into a reamed or bored hole in your fixture plate, ensuring the bushing is seated flush or slightly below the surface. Use a press or arbor to avoid damaging the bushing, and verify alignment with the locating pin.
