KIPP Tapped Gripper w/Serrated Pad: M6, 7 mm Tap Dp, 10 mm Pad Dia, 28 kN Max Load - Tapped Grippers with Serrated Steel Pad
KIPPTapped Grippers with Serrated Steel Pad

KIPP Tapped Gripper w/Serrated Pad: M6, 7 mm Tap Dp, 10 mm Pad Dia, 28 kN Max Load

The KIPP Tapped Gripper with Serrated Steel Pad (MPN K0285.317X022) is a workholding component with an M6 thread, 7 mm tap depth, and a 10 mm serrated pad diameter. It supports a maximum load of 28 kN and has a 17 mm…

SKU 3G-OTH-181626

Brand
KIPP
Item
Tapped Gripper w/Serrated Pad: M6, 7 mm Tap Dp, 10 mm Pad Dia, 28 kN Max Load
Category
Tapped Grippers with Serrated Steel Pad
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

KIPP
Manufacturer Part Number
K0285.317X022
Type
Steel
OD
17 mm
Tap Dp
7 mm
Pad Dia
10 mm
Max Load
28 kN
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

KIPP Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The KIPP Tapped Gripper with Serrated Steel Pad (MPN K0285.317X022) is a workholding component with an M6 thread, 7 mm tap depth, and a 10 mm serrated pad diameter. It supports a maximum load of 28 kN and has a 17 mm outer diameter, constructed from steel. 3G Electric interprets customer demand and delivers this genuine industrial gripper across 14 departments—including machining and material handling—with specialist depth in combustion, pumps, and controls as an authorised distributor.

Frequently Asked Questions

What is a KIPP tapped gripper with serrated pad used for?

A KIPP tapped gripper with serrated steel pad is used in jigs, fixtures, and workholding systems to securely clamp and position parts during machining, assembly, or inspection. The serrated pad provides high grip on metal, plastic, or composite surfaces, preventing slippage under load.

What are the specifications of the KIPP K0285.317X022 tapped gripper?

The KIPP K0285.317X022 tapped gripper has an M6 thread, 7 mm tap depth, 10 mm pad diameter, 17 mm outer diameter, and a maximum load of 28 kN. It is made of steel with a serrated pad for high clamping force in industrial workholding applications.

Where to buy KIPP tapped grippers worldwide?

3G Electric supplies KIPP tapped grippers worldwide, handling full logistics, customs clearance, and delivery to your facility. As a global industrial sourcing partner, we provide genuine KIPP components like the K0285.317X022 with serrated steel pad for workholding systems.

How to select the right KIPP tapped gripper for a fixture?

Select a KIPP tapped gripper by matching thread size (e.g., M6), pad diameter, and maximum load (28 kN for this model) to your fixture's clamping force and workpiece material. Ensure tap depth (7 mm) accommodates your mounting hole. Serrated pads suit high-grip applications on hard surfaces.

Used in

Common applications for KIPP
Jig and fixture construction — KIPP indexing plungers (e.g., SKU 53EC55) for repeatable workpiece positioning
Assembly line tooling — KIPP threaded grippers with flat pads (e.g., SKU 801Y95) for clamping components
Machine tool alignment — KIPP tapered-head locating pins (e.g., SKU 801XY4) for precise part registration
Sanitary processing equipment — KIPP hygienic sockets (e.g., SKU 802KU2) for tooling in food-grade environments
Abrasive material handling — KIPP diamond-faced inserts (e.g., SKU 801XH6) for gripping in dusty or gritty conditions
Fixture leveling and support — KIPP positioning feet with flat faces (e.g., SKU 615V08) for stable machine setup

KIPP Products

3G Electric supplies KIPP tapped grippers with serrated steel pad. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
