KIPP Tapped Gripper w/Serrated Pad: M10, 8 mm Tap Dp, 16 mm Pad Dia, 58 kN Max Load - Tapped Grippers with Serrated Steel Pad
KIPPTapped Grippers with Serrated Steel Pad

KIPP Tapped Gripper w/Serrated Pad: M10, 8 mm Tap Dp, 16 mm Pad Dia, 58 kN Max Load

SKU 3G-OTH-181624

Brand
KIPP
Item
Tapped Gripper w/Serrated Pad: M10, 8 mm Tap Dp, 16 mm Pad Dia, 58 kN Max Load
Category
Tapped Grippers with Serrated Steel Pad
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

KIPP
Manufacturer Part Number
K0285.324X028
Type
Steel
OD
24 mm
Tap Dp
8 mm
Pad Dia
16 mm
Max Load
58 kN
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

KIPP Products
3G Electric (S) Pte. Ltd. — Singapore

Frequently Asked Questions

What is a KIPP tapped gripper with serrated pad used for?

A KIPP tapped gripper with serrated steel pad is used in industrial workholding and fixturing to securely clamp or position parts during machining, assembly, or inspection. The serrated pad provides high grip on irregular surfaces, while the tapped mounting allows direct attachment to fixtures or machine tables.

What are the specifications of the KIPP K0285.324X028 tapped gripper?

The KIPP K0285.324X028 tapped gripper has an M10 thread, 8 mm tap depth, 16 mm pad diameter, 24 mm outer diameter, and a maximum load of 58 kN. It features a serrated steel pad for high grip and is made from steel. 3G Electric supplies this genuine KIPP component worldwide.

Where to buy KIPP tapped grippers with serrated pad worldwide?

3G Electric supplies KIPP tapped grippers with serrated pad to customers worldwide. We handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on the K0285.324X028 or other KIPP workholding components.

How to install a KIPP tapped gripper with serrated pad?

Install the KIPP tapped gripper by threading the M10 stud into a matching tapped hole in your fixture or machine table. Tighten to the recommended torque for steel components. Ensure the serrated pad contacts the workpiece evenly to avoid marring. 3G Electric provides sourcing support for this KIPP part.

Used in

Common applications for KIPP
Jig and fixture construction — KIPP indexing plungers (e.g., SKU 53EC55) for repeatable workpiece positioning
Assembly line tooling — KIPP threaded grippers with flat pads (e.g., SKU 801Y95) for clamping components
Machine tool alignment — KIPP tapered-head locating pins (e.g., SKU 801XY4) for precise part registration
Sanitary processing equipment — KIPP hygienic sockets (e.g., SKU 802KU2) for tooling in food-grade environments
Abrasive material handling — KIPP diamond-faced inserts (e.g., SKU 801XH6) for gripping in dusty or gritty conditions
Fixture leveling and support — KIPP positioning feet with flat faces (e.g., SKU 615V08) for stable machine setup
