LITTLE GIANT Sewage Ejector System: Plastic, 2/5 hp, 120V AC, 70 gpm @ 10' of Head - Simplex Sewage Grinder Pump Packages
LITTLE GIANTSimplex Sewage Grinder Pump Packages

LITTLE GIANT Sewage Ejector System: Plastic, 2/5 hp, 120V AC, 70 gpm @ 10' of Head

The LITTLE GIANT Sewage Ejector System: Plastic (SKU 44ZH93, MPN 509685) is a simplex sewage grinder pump package rated at 2/5 hp, 120V AC, delivering 70 gpm at 10 feet of head with a 20 ft maximum head. It features…

SKU 3G-OTH-84436

Brand
LITTLE GIANT
Item
Sewage Ejector System: Plastic, 2/5 hp, 120V AC, 70 gpm @ 10' of Head
Category
Simplex Sewage Grinder Pump Packages
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LITTLE GIANT
Manufacturer Part Number
509685
Type
2/5 hp, 70 gpm @ 10' of Head
AC
120V
Alarm
Not Included
Switch
Diaphragm
Max. Head
20 ft
Rated Voltage
120V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LITTLE GIANT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LITTLE GIANT Sewage Ejector System: Plastic (SKU 44ZH93, MPN 509685) is a simplex sewage grinder pump package rated at 2/5 hp, 120V AC, delivering 70 gpm at 10 feet of head with a 20 ft maximum head. It features a diaphragm switch and does not include an alarm.

Frequently Asked Questions

What is a LITTLE GIANT sewage ejector system used for?

A LITTLE GIANT sewage ejector system pumps wastewater from below-grade fixtures like basements up to the main sewer line. This simplex grinder package handles solids, making it suitable for residential and light commercial applications where gravity drainage is not possible.

What are the specifications of the LITTLE GIANT 509685 sewage ejector system?

The LITTLE GIANT 509685 is a 2/5 hp simplex sewage grinder pump package rated at 120V AC. It delivers 70 gpm at 10 feet of head with a 20 ft maximum head. It uses a diaphragm switch and does not include an alarm.

Where to buy a LITTLE GIANT sewage ejector system worldwide?

3G Electric supplies the LITTLE GIANT sewage ejector system worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and a quote for the 509685 model.

How to install a LITTLE GIANT sewage ejector system?

Installation requires a dedicated 120V AC circuit, proper venting, and a discharge line to the sewer. Secure the basin, connect the pump with a diaphragm switch, and test for leaks. Always follow local plumbing codes and the manufacturer's manual for safe operation.
