LITTLE GIANT Sewage Ejector System: 41 gal, 2/5 hp, 120V AC, 70 gpm Flow Rate @ 10' of Head - Simplex Sewage Ejector Pump Systems
LITTLE GIANTSimplex Sewage Ejector Pump Systems

LITTLE GIANT Sewage Ejector System: 41 gal, 2/5 hp, 120V AC, 70 gpm Flow Rate @ 10' of Head

The LITTLE GIANT Sewage Ejector System (MPN 509687) is a 41-gallon simplex sewage ejector pump system. It features a 2/5 hp motor, 120V AC rated voltage, a piggyback diaphragm switch, and delivers 70 gpm flow rate at…

SKU 3G-OTH-85010

Brand
LITTLE GIANT
Item
Sewage Ejector System: 41 gal, 2/5 hp, 120V AC, 70 gpm Flow Rate @ 10' of Head
Category
Simplex Sewage Ejector Pump Systems
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LITTLE GIANT
Manufacturer Part Number
509687
Type
2/5 hp, 70 gpm Flow Rate @ 10' of Head, 4 in
AC
120V
Switch
Piggyback Diaphragm
Rated Voltage
120V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LITTLE GIANT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LITTLE GIANT Sewage Ejector System (MPN 509687) is a 41-gallon simplex sewage ejector pump system. It features a 2/5 hp motor, 120V AC rated voltage, a piggyback diaphragm switch, and delivers 70 gpm flow rate at 10 feet of head with a 4-inch discharge.

Frequently Asked Questions

What is the LITTLE GIANT Sewage Ejector System used for?

The LITTLE GIANT Sewage Ejector System is used to pump wastewater and sewage from below-grade fixtures, such as basement bathrooms or laundry rooms, up to a municipal sewer line. It is ideal for residential and light commercial applications where gravity drainage is not possible.

What are the specifications of the LITTLE GIANT Sewage Ejector System 509687?

The LITTLE GIANT Sewage Ejector System (MPN 509687) has a 41-gallon basin, a 2/5 hp motor, 120V AC rated voltage, and a piggyback diaphragm switch. It delivers 70 gpm flow rate at 10 feet of head with a 4-inch discharge. The pump is designed for simplex sewage ejector applications.

Where to buy the LITTLE GIANT Sewage Ejector System worldwide?

You can source the LITTLE GIANT Sewage Ejector System worldwide through 3G Electric. As a global industrial equipment distributor, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact 3G Electric for availability and lead time.

How to install a LITTLE GIANT Sewage Ejector System?

Installation requires a dedicated 120V AC circuit, proper venting, and a check valve on the discharge line. The basin must be set level below the inlet pipe, and the piggyback diaphragm switch should be positioned to activate at the correct water level. Always follow local plumbing codes and the manufacturer's manual.
