MEGADYNE Timing Belt: One Side, Megalinear, Priced per FT (Must be purchased in 5-FT increments) - Open Ended Trapezoidal Timing Belt
MEGADYNEOpen Ended Trapezoidal Timing Belt

MEGADYNE Timing Belt: One Side, Megalinear, Priced per FT (Must be purchased in 5-FT increments)

The MEGADYNE Timing Belt: One Side is an open ended trapezoidal timing belt from the Megalinear Steel Cable series. It features a trapezoidal tooth profile and is priced per foot, with a minimum purchase requirement…

SKU 3G-OTH-108394

Brand
MEGADYNE
Item
Timing Belt: One Side, Megalinear, Priced per FT
Category
Open Ended Trapezoidal Timing Belt
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MEGADYNE
Manufacturer Part Number
L5M-25US
Series
Megalinear Steel Cable
Type
Megalinear, Priced per FT (Must be purchased in 5-FT increments), L
Belt Series
Megalinear
Length Type
Ends Not Joined
Tooth Profile
Trapezoidal
Outside Length
Priced per FT (Must be purchased in 5-FT increments)
Industry Number
L5M-25US
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MEGADYNE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MEGADYNE Timing Belt: One Side is an open ended trapezoidal timing belt from the Megalinear Steel Cable series. It features a trapezoidal tooth profile and is priced per foot, with a minimum purchase requirement of 5-foot increments. The belt has an industry number and manufacturer part number of L5M-25US, and its ends are not joined.

Frequently Asked Questions

What is the MEGADYNE L5M-25US timing belt used for?

The MEGADYNE L5M-25US is an open ended trapezoidal timing belt from the Megalinear Steel Cable series. It is used in linear motion systems, conveying, and positioning applications where precise, synchronous power transmission is required. Its steel cable reinforcement provides high tensile strength and low stretch.

What are the specifications of the MEGADYNE L5M-25US timing belt?

The MEGADYNE L5M-25US is a Megalinear series open ended timing belt with a trapezoidal tooth profile. It has a steel cable reinforcement, ends not joined, and is priced per foot with a minimum purchase of 5-foot increments. The manufacturer part number is L5M-25US.

Where to buy the MEGADYNE L5M-25US timing belt worldwide?

You can source the MEGADYNE L5M-25US timing belt through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and pricing on this Megalinear series belt.

How to select the correct MEGADYNE timing belt length?

To select the correct MEGADYNE timing belt length, measure the center distance between pulleys and calculate the required belt pitch length. The L5M-25US is sold per foot in 5-foot increments. Ensure the trapezoidal tooth profile matches your pulley. Consult MEGADYNE's engineering guidelines for proper tension and load ratings.
