MEGADYNE Timing Belts: Megalinear, Priced per FT (Must be purchased in 5-FT increments) - Open Ended Trapezoidal Timing Belt
MEGADYNEOpen Ended Trapezoidal Timing Belt

MEGADYNE Timing Belts: Megalinear, Priced per FT (Must be purchased in 5-FT increments)

The MEGADYNE Megalinear is an open-ended trapezoidal timing belt from the Megalinear Steel Cable series, priced per foot and sold in 5-foot increments. It features a 5 mm pitch, trapezoidal tooth profile, and ends…

SKU 3G-OTH-108827

Brand
MEGADYNE
Item
Timing Belts: Megalinear, Priced per FT
Category
Open Ended Trapezoidal Timing Belt
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MEGADYNE
Manufacturer Part Number
L25AT5
Series
Megalinear Steel Cable
Type
Priced per FT (Must be purchased in 5-FT increments)
Pitch
5 mm
Belt Series
Megalinear
Length Type
Ends Not Joined
Tooth Profile
Trapezoidal
Outside Length
Priced per FT (Must be purchased in 5-FT increments)
Industry Number
L25AT5
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MEGADYNE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MEGADYNE Megalinear is an open-ended trapezoidal timing belt from the Megalinear Steel Cable series, priced per foot and sold in 5-foot increments. It features a 5 mm pitch, trapezoidal tooth profile, and ends not joined, with industry number L25AT5.

Frequently Asked Questions

What is a MEGADYNE Megalinear timing belt used for?

The MEGADYNE Megalinear open-ended trapezoidal timing belt is used for linear positioning and power transmission in industrial automation, packaging, and material handling systems. Its 5 mm pitch and steel cable reinforcement provide precise motion control and high tensile strength for demanding applications.

What are the specifications of the MEGADYNE L25AT5 timing belt?

The MEGADYNE L25AT5 is a Megalinear Steel Cable series open-ended timing belt with a 5 mm pitch, trapezoidal tooth profile, and ends not joined. It is priced per foot and must be purchased in 5-foot increments. The industry number is L25AT5.

Where to buy MEGADYNE timing belts worldwide?

3G Electric supplies MEGADYNE Megalinear timing belts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to order the L25AT5 or other MEGADYNE belt series for your application.

How to select the right MEGADYNE timing belt length?

To select the correct MEGADYNE Megalinear timing belt length, measure the center distance between pulleys and calculate the required belt perimeter. The L25AT5 is sold per foot in 5-foot increments, so order the nearest length that meets your drive design. Consult MEGADYNE's engineering guidelines for tension and load ratings.
