MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator: 1,000 psig Max - Differential Pressure Indicators with Switch
MIDWEST INSTRUMENTDifferential Pressure Indicators with Switch

MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator: 1,000 psig Max

The MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator (MPN 522A-010-LA) is a differential pressure indicator with switch, featuring a maximum static pressure of 1,000 psig. It offers ±5% of Full Scale…

SKU 3G-OTH-174307

Brand
MIDWEST INSTRUMENT
Item
3-Color Differential Pressure Indicator: 1,000 psig Max
Category
Differential Pressure Indicators with Switch
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MIDWEST INSTRUMENT
Manufacturer Part Number
522A-010-LA
Type
Static Pressure, 522
Accuracy
±5% of Full Scale
Sensor Material
Buna-N
Housing Material
Aluminum
Transition Points
0 psid to 5 psid (Green) / 5 psid to 7 psid (Yellow) / 7 psid to 10 psid (Red)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MIDWEST INSTRUMENT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator (MPN 522A-010-LA) is a differential pressure indicator with switch, featuring a maximum static pressure of 1,000 psig. It offers ±5% of Full Scale accuracy, with a Buna-N sensor and aluminum housing. The indicator transitions through three color zones: Green from 0 psid to 5 psid, Yellow from 5 psid to 7 psid, and Red from 7 psid to 10 psid.

Frequently Asked Questions

What is the MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator used for?

This indicator visually shows differential pressure across filters, strainers, or pumps in industrial fluid systems. Its three-color scale (green, yellow, red) provides at-a-glance status from normal to warning to critical, helping plant engineers and maintenance techs schedule service before failure.

What are the specifications of the MIDWEST INSTRUMENT 522A-010-LA?

The MIDWEST INSTRUMENT 522A-010-LA has a maximum static pressure of 1,000 psig, accuracy of ±5% of Full Scale, a Buna-N sensor, and an aluminum housing. Transition points are 0 psid to 5 psid (green), 5 psid to 7 psid (yellow), and 7 psid to 10 psid (red).

Where to buy the MIDWEST INSTRUMENT 522A-010-LA worldwide?

3G Electric supplies the MIDWEST INSTRUMENT 522A-010-LA differential pressure indicator to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this part.

How to install the MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator?

Install the indicator in a vertical or horizontal pipe run using compatible fittings, ensuring the pressure ports align with system flow direction. Avoid overtightening the aluminum housing. For best accuracy, mount away from vibration sources and verify the Buna-N sensor is compatible with your fluid.

Used in

Common applications for MIDWEST INSTRUMENT
Filter monitoring in industrial water treatment — MIDWEST INSTRUMENT 522 series 3-color differential pressure indicators
Flow measurement in chemical processing — MIDWEST INSTRUMENT Series 120 piston-type differential pressure gauges
Liquid level indication in oil and gas storage tanks — MIDWEST INSTRUMENT Model 142 diaphragm-type differential pressure gauges
HVAC system filter condition monitoring — MIDWEST INSTRUMENT Series 130 differential pressure gauges with glass-reinforced plastic housing
Pump differential pressure monitoring in industrial plants — MIDWEST INSTRUMENT 522 series indicators with switch for alarm output
