MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator: 1,000 psig Max - Differential Pressure Indicators with Switch
MIDWEST INSTRUMENTDifferential Pressure Indicators with Switch

MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator: 1,000 psig Max

The MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator (MPN 522P-015-LA) is a differential pressure indicator with switch, featuring a Buna-N sensor and Acetal Plastic housing. It offers ±5% of Full Scale…

SKU 3G-OTH-174316

Brand
MIDWEST INSTRUMENT
Item
3-Color Differential Pressure Indicator: 1,000 psig Max
Category
Differential Pressure Indicators with Switch
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MIDWEST INSTRUMENT
Manufacturer Part Number
522P-015-LA
Type
Static Pressure, 522
Accuracy
±5% of Full Scale
Sensor Material
Buna-N
Housing Material
Acetal Plastic
Transition Points
0 psid to 7.5 psid (Green) / 7.5 psid to 11 psid (Yellow) / 11 psid to 15 psid (Red)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MIDWEST INSTRUMENT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator (MPN 522P-015-LA) is a differential pressure indicator with switch, featuring a Buna-N sensor and Acetal Plastic housing. It offers ±5% of Full Scale accuracy and color-coded transition points: green from 0 psid to 7.5 psid, yellow from 7.5 psid to 11 psid, and red from 11 psid to 15 psid, with a maximum static pressure of 1,000 psig.

Frequently Asked Questions

What is the MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator used for?

This indicator provides a visual status of differential pressure in fluid systems, using green, yellow, and red zones to show filter condition or flow status. It is commonly applied in HVAC, water treatment, and process industries where monitoring pressure drops across filters or strainers is critical.

What are the specifications of the MIDWEST INSTRUMENT 522P-015-LA?

The MIDWEST INSTRUMENT 522P-015-LA has a maximum static pressure of 1,000 psig, accuracy of ±5% of full scale, a Buna-N sensor, and an Acetal Plastic housing. Transition points are color-coded: green from 0 psid to 7.5 psid, yellow from 7.5 psid to 11 psid, and red from 11 psid to 15 psid.

Where to buy the MIDWEST INSTRUMENT 522P-015-LA worldwide?

3G Electric supplies the MIDWEST INSTRUMENT 522P-015-LA to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time; we source genuine industrial equipment across 14 departments including instrumentation and controls.

How to install the MIDWEST INSTRUMENT 3-Color Differential Pressure Indicator?

Install the indicator in a clean, dry location within the specified pressure range. Use appropriate fittings for the Buna-N sensor and Acetal housing. Ensure the process connections are tight and free of debris. Refer to the manufacturer's manual for detailed mounting orientation and electrical wiring of the switch.

Used in

Common applications for MIDWEST INSTRUMENT
Filter monitoring in industrial water treatment — MIDWEST INSTRUMENT 522 series 3-color differential pressure indicators
Flow measurement in chemical processing — MIDWEST INSTRUMENT Series 120 piston-type differential pressure gauges
Liquid level indication in oil and gas storage tanks — MIDWEST INSTRUMENT Model 142 diaphragm-type differential pressure gauges
HVAC system filter condition monitoring — MIDWEST INSTRUMENT Series 130 differential pressure gauges with glass-reinforced plastic housing
Pump differential pressure monitoring in industrial plants — MIDWEST INSTRUMENT 522 series indicators with switch for alarm output
