NTN Pillow Block Bearing: 1 in Bore, Cast Iron, Eccentric Collar, 1 19/64 in Shaft Ht - Low-Base Pillow Block Ball Bearings
NTNLow-Base Pillow Block Ball Bearings

NTN Pillow Block Bearing: 1 in Bore, Cast Iron, Eccentric Collar, 1 19/64 in Shaft Ht

The NTN Low-Base Pillow Block Ball Bearing (SKU 5RZH9, MPN UELPL-1M) is a 1-inch bore, cast-iron unit with an eccentric collar and a shaft height of 1 19/64 inches. It has a maximum speed of 5,900 RPM and uses M10…

SKU 3G-OTH-102597

Brand
NTN
Item
Pillow Block Bearing: 1 in Bore, Cast Iron, Eccentric Collar, 1 19/64 in Shaft Ht
Category
Low-Base Pillow Block Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

NTN
Manufacturer Part Number
UELPL-1M
Type
Cast Iron, Eccentric Collar, 5,900 RPM
Shaft Ht
1 19/64 in
Maximum Speed
5,900 RPM
Mounting Bolt Size
M10
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

NTN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The NTN Low-Base Pillow Block Ball Bearing (SKU 5RZH9, MPN UELPL-1M) is a 1-inch bore, cast-iron unit with an eccentric collar and a shaft height of 1 19/64 inches. It has a maximum speed of 5,900 RPM and uses M10 mounting bolts, designed for inch-system applications.

Frequently Asked Questions

What is the NTN UELPL-1M pillow block bearing used for?

The NTN UELPL-1M low-base pillow block bearing supports rotating shafts in industrial machinery such as conveyors, fans, and pumps. Its cast-iron housing and eccentric collar lock the bearing to the shaft, making it suitable for moderate-speed, inch-system applications up to 5,900 RPM.

What are the specifications of the NTN UELPL-1M pillow block bearing?

The NTN UELPL-1M has a 1-inch bore, cast-iron housing with an eccentric collar, a shaft height of 1 19/64 inches, and a maximum speed of 5,900 RPM. It uses M10 mounting bolts and is designed for inch-system measurements. The manufacturer part number is UELPL-1M.

Where to buy the NTN UELPL-1M pillow block bearing worldwide?

3G Electric supplies the NTN UELPL-1M pillow block bearing worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this NTN bearing to any country.

How to install the NTN UELPL-1M pillow block bearing?

To install the NTN UELPL-1M, first clean the shaft and housing bore. Slide the bearing onto the shaft, align the eccentric collar with the bearing inner ring, and rotate the collar in the direction of shaft rotation to lock it. Tighten the setscrew, then secure the housing with M10 bolts. Ensure proper lubrication before operation.
