NTN Pillow Block Bearing: 3/4 in Bore, Cast Iron, Eccentric Collar, 1 1/4 in Shaft Ht - Low-Base Pillow Block Ball Bearings
NTNLow-Base Pillow Block Ball Bearings

NTN Pillow Block Bearing: 3/4 in Bore, Cast Iron, Eccentric Collar, 1 1/4 in Shaft Ht

The NTN UELPL-3/4M is a low-base pillow block ball bearing with a 3/4-inch bore, constructed from cast iron and featuring an eccentric collar. It has a maximum speed of 6,700 RPM, a shaft height of 1 1/4 inches, and…

SKU 3G-OTH-104896

Brand
NTN
Item
Pillow Block Bearing: 3/4 in Bore, Cast Iron, Eccentric Collar, 1 1/4 in Shaft Ht
Category
Low-Base Pillow Block Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

NTN
Manufacturer Part Number
UELPL-3/4M
Type
Cast Iron, Eccentric Collar, 6,700 RPM
Shaft Ht
1 1/4 in
Maximum Speed
6,700 RPM
Mounting Bolt Size
M10
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

NTN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The NTN UELPL-3/4M is a low-base pillow block ball bearing with a 3/4-inch bore, constructed from cast iron and featuring an eccentric collar. It has a maximum speed of 6,700 RPM, a shaft height of 1 1/4 inches, and uses an M10 mounting bolt size. This inch-system bearing is designed for industrial applications requiring a compact, low-base mounting configuration.

Frequently Asked Questions

What is the NTN UELPL-3/4M pillow block bearing used for?

The NTN UELPL-3/4M low-base pillow block ball bearing is used in industrial machinery requiring compact mounting and moderate-speed shaft support. Common applications include conveyors, fans, and material handling equipment where a 3/4-inch bore and cast iron housing with eccentric collar provide reliable alignment and load distribution.

What are the specifications of the NTN UELPL-3/4M bearing?

The NTN UELPL-3/4M has a 3/4-inch bore, cast iron housing, and eccentric collar locking. Maximum speed is 6,700 RPM. Shaft height is 1 1/4 inches, mounting bolt size is M10, and system of measurement is inch. This low-base design suits applications with limited vertical space.

Where to buy the NTN UELPL-3/4M bearing worldwide?

3G Electric supplies the NTN UELPL-3/4M pillow block bearing worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this NTN bearing.

How to install the NTN UELPL-3/4M eccentric collar bearing?

To install the NTN UELPL-3/4M, slide the bearing onto a clean shaft, align the eccentric collar with the inner ring notch, and rotate the collar in the shaft rotation direction to lock. Tighten the setscrew. Use M10 bolts to mount the cast iron base to a flat surface. Ensure shaft alignment to prevent premature wear.
