Parker Subplate Bottom Port: 5,000 psi Max Pressure, D03 NFPA Size, Ductile Iron - Valve Subplates
ParkerValve Subplates

Parker Subplate Bottom Port: 5,000 psi Max Pressure, D03 NFPA Size, Ductile Iron

The PARKER Subplate Bottom Port is a valve subplate designed for D03 NFPA size valves, featuring a ductile iron body and NPT port connections. It supports a maximum pressure of 5,000 psi and has an overall height of…

SKU 3G-OTH-172950

Brand
Parker
Item
Subplate Bottom Port: 5,000 psi Max Pressure, D03 NFPA Size, Ductile Iron
Category
Valve Subplates
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Parker
Manufacturer Part Number
SPD22NS35
Type
D03 NFPA Size, Ductile Iron
NFPA Size
D03
Overall Ht
2.5 in
Body Material
Ductile Iron
Port Connection Type
NPT
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Parker Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PARKER Subplate Bottom Port is a valve subplate designed for D03 NFPA size valves, featuring a ductile iron body and NPT port connections. It supports a maximum pressure of 5,000 psi and has an overall height of 2.5 inches, with manufacturer part number SPD22NS35.

Frequently Asked Questions

What is the PARKER Subplate Bottom Port used for?

The PARKER Subplate Bottom Port is a valve subplate used to mount and connect D03 NFPA size hydraulic valves. It provides a secure mounting interface and porting for fluid power systems in industrial machinery, mobile equipment, and automation applications requiring reliable hydraulic control.

What are the specifications of the PARKER Subplate Bottom Port?

The PARKER Subplate Bottom Port has a ductile iron body, D03 NFPA size, and NPT port connections. It supports a maximum pressure of 5,000 psi and has an overall height of 2.5 inches. The manufacturer part number is SPD22NS35.

Where to buy the PARKER Subplate Bottom Port worldwide?

You can source the PARKER Subplate Bottom Port through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the PARKER Subplate Bottom Port?

Mount the subplate on a clean, flat surface using appropriate bolts. Connect hydraulic lines to the NPT ports, ensuring proper sealing with thread sealant. Install the D03 valve onto the subplate and torque mounting bolts to manufacturer specifications. Always follow standard hydraulic safety practices.
