Parker Subplate Side Port: 5,000 psi Max Pressure, D03 NFPA Size, Ductile Iron - Valve Subplates
ParkerValve Subplates

Parker Subplate Side Port: 5,000 psi Max Pressure, D03 NFPA Size, Ductile Iron

The PARKER Subplate Side Port is a valve subplate designed for D03 NFPA size valves, featuring a ductile iron body and a maximum pressure rating of 5,000 psi. This model, MPN SPD24SAS35, has an overall height of 3.5…

SKU 3G-OTH-172947

Brand
Parker
Item
Subplate Side Port: 5,000 psi Max Pressure, D03 NFPA Size, Ductile Iron
Category
Valve Subplates
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Parker
Manufacturer Part Number
SPD24SAS35
Type
D03 NFPA Size, Ductile Iron
NFPA Size
D03
Overall Ht
3.5 in
Body Material
Ductile Iron
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Parker Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PARKER Subplate Side Port is a valve subplate designed for D03 NFPA size valves, featuring a ductile iron body and a maximum pressure rating of 5,000 psi. This model, MPN SPD24SAS35, has an overall height of 3.5 inches and is configured for side porting.

Frequently Asked Questions

What is the PARKER Subplate Side Port used for?

The PARKER Subplate Side Port (MPN SPD24SAS35) is a valve subplate used to mount and connect D03 NFPA size hydraulic valves. It provides a ductile iron manifold with side porting for secure, leak-free fluid routing in industrial hydraulic systems up to 5,000 psi.

What are the specifications of the PARKER Subplate Side Port?

This PARKER subplate has a D03 NFPA size, ductile iron body, maximum pressure rating of 5,000 psi, and overall height of 3.5 in. It is configured for side porting and carries manufacturer part number SPD24SAS35.

Where to buy the PARKER Subplate Side Port worldwide?

3G Electric supplies the PARKER Subplate Side Port (SPD24SAS35) to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive genuine PARKER valve subplates for your hydraulic systems.

How to select the correct PARKER Subplate for a D03 valve?

To select the correct PARKER subplate, match the NFPA size (D03), porting style (side port), pressure rating (5,000 psi max), and body material (ductile iron) to your valve and system requirements. Verify the overall height of 3.5 in fits your mounting space.
