SCHNEIDER Enclosed Power Relay: DIN-Rail & Surface Mounted, 30 A Current Rating, 12V DC - Combination DIN-Rail & Surface-Mounted Relays
SCHNEIDERCombination DIN-Rail & Surface-Mounted Relays

SCHNEIDER Enclosed Power Relay: DIN-Rail & Surface Mounted, 30 A Current Rating, 12V DC

The SCHNEIDER Harmony™ RPF Power Series enclosed power relay (MPN RPF2BJD) is a combination DIN-rail and surface-mounted relay with a square body and a DIN Rail & Top Flange mounting style. It features a 1/4 in tab…

SKU 3G-OTH-137570

Brand
SCHNEIDER
Item
Enclosed Power Relay: DIN-Rail & Surface Mounted, 30 A Current Rating, 12V DC
Category
Combination DIN-Rail & Surface-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
RPF2BJD
Type
DPDT
DC
12V
Current Rating
30 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Harmony™ RPF Power Series enclosed power relay (MPN RPF2BJD) is a combination DIN-rail and surface-mounted relay with a square body and a DIN Rail & Top Flange mounting style. It features a 1/4 in tab terminal and a normally closed (NC) UL rating of 3 A at 28V DC.

Frequently Asked Questions

What is the SCHNEIDER RPF2BJD enclosed power relay used for?

The SCHNEIDER Harmony RPF Power Series enclosed power relay (RPF2BJD) is used for switching and controlling industrial loads up to 30 A in panel-building, automation, and process-control applications. Its DIN-rail and surface-mount design suits both new installations and retrofits in factories, HVAC systems, and machinery.

What are the specifications of the SCHNEIDER RPF2BJD relay?

The SCHNEIDER RPF2BJD is a DPDT enclosed power relay rated for 30 A at 12V DC. It has a square body, DIN Rail & Top Flange mounting, and a 1/4 in tab terminal. The NC contact carries a UL rating of 3 A at 28V DC. It is part of the Harmony RPF Power Series.

Where to buy the SCHNEIDER RPF2BJD relay worldwide?

You can source the SCHNEIDER RPF2BJD relay worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time; we supply genuine SCHNEIDER components to any country.

How to install the SCHNEIDER RPF2BJD relay on a DIN rail?

To install the SCHNEIDER RPF2BJD, clip the relay onto a standard 35 mm DIN rail until it locks. For surface mounting, use the top flange holes with appropriate screws. Wire the 1/4 in tab terminals per the DPDT coil and contact ratings. Ensure the 12V DC coil voltage matches your control circuit.
