SCHNEIDER General Purpose Relay: Socket Mounted, 6 A Current Rating, 120V AC, 4PDT - Socket-Mounted Relays
SCHNEIDERSocket-Mounted Relays

SCHNEIDER General Purpose Relay: Socket Mounted, 6 A Current Rating, 120V AC, 4PDT

The SCHNEIDER General Purpose Relay is a socket-mounted relay from the Square D 8501R Miniature Control Series. It features a square base with flat pins, a quick-connect electrical connection, and a 4PDT contact…

SKU 3G-OTH-43169

Brand
SCHNEIDER
Item
General Purpose Relay: Socket Mounted, 6 A Current Rating, 120V AC, 4PDT
Category
Socket-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
8501RS14P14V20
Series
Square D 8501R Miniature Control Series
Type
4PDT, G Socket
AC
120V
Base Type
Square
Pin Shape
Flat
Current Rating
6 A
Mounting Style
Socket
Electrical Connection
Quick-Connect
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER General Purpose Relay is a socket-mounted relay from the Square D 8501R Miniature Control Series. It features a square base with flat pins, a quick-connect electrical connection, and a 4PDT contact configuration. This relay is rated for 6 A at 120V AC and uses a G socket (MPN 8501RS14P14V20).

Frequently Asked Questions

What is the SCHNEIDER 8501RS14P14V20 relay used for?

The SCHNEIDER 8501RS14P14V20 is a general-purpose relay used for switching and control in industrial automation, HVAC, and panel-building applications. Its 4PDT contact configuration and 6 A rating at 120V AC make it suitable for pilot duty, signal switching, and interposing relay functions in control circuits.

What are the specifications of the SCHNEIDER 8501RS14P14V20 relay?

This SCHNEIDER relay from the Square D 8501R Miniature Control Series has a 4PDT contact arrangement, 6 A current rating at 120V AC, and a square base with flat pins. It mounts via a G socket (included) and uses quick-connect electrical connections. The manufacturer part number is 8501RS14P14V20.

Where to buy the SCHNEIDER 8501RS14P14V20 relay worldwide?

3G Electric supplies the SCHNEIDER 8501RS14P14V20 relay worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this Square D 8501R series relay to any country.

How to install the SCHNEIDER 8501RS14P14V20 socket-mounted relay?

To install, mount the G socket (MPN 8501RS14P14V20) on a DIN rail or panel, wire the quick-connect terminals per your control schematic, then firmly press the relay into the socket until it latches. Ensure the coil voltage matches your 120V AC supply. Always de-energize circuits before installation.
