SCHNEIDER Miniature IEC Magnetic Contactor: Reversing, 3 Poles, 3NO Contacts, 9 A - Miniature, Reversing IEC Contactors
SCHNEIDERMiniature, Reversing IEC Contactors

SCHNEIDER Miniature IEC Magnetic Contactor: Reversing, 3 Poles, 3NO Contacts, 9 A

The SCHNEIDER Miniature IEC Magnetic Contactor: Reversing (MPN LP2K0901BD) is a 3-pole, 3NO contact reversing contactor rated at 9 A with a 24V DC coil. This miniature IEC contactor does not include integrated surge…

SKU 3G-OTH-40833

Brand
SCHNEIDER
Item
Miniature IEC Magnetic Contactor: Reversing, 3 Poles, 3NO Contacts, 9 A
Category
Miniature, Reversing IEC Contactors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LP2K0901BD
Type
9 A
Poles
3
DC Coil
24V
Contacts
3NO
Integrated Surge Suppression
No
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Miniature IEC Magnetic Contactor: Reversing (MPN LP2K0901BD) is a 3-pole, 3NO contact reversing contactor rated at 9 A with a 24V DC coil. This miniature IEC contactor does not include integrated surge suppression.

Frequently Asked Questions

What is the SCHNEIDER LP2K0901BD reversing contactor used for?

The SCHNEIDER LP2K0901BD is a miniature IEC reversing magnetic contactor used to control the forward and reverse rotation of three-phase motors in industrial applications such as conveyors, pumps, and hoists. Its 3-pole, 3NO configuration and 9 A rating suit light-duty reversing motor control.

What are the specifications of the SCHNEIDER LP2K0901BD contactor?

The SCHNEIDER LP2K0901BD is a reversing miniature IEC magnetic contactor with 3 poles and 3 normally open contacts. It is rated at 9 A and has a 24V DC coil. It does not include integrated surge suppression. The brand is SCHNEIDER and the MPN is LP2K0901BD.

Where to buy the SCHNEIDER LP2K0901BD contactor worldwide?

You can source the SCHNEIDER LP2K0901BD reversing contactor through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the right reversing contactor for a motor application?

To select a reversing contactor like the SCHNEIDER LP2K0901BD, match the contactor's rated current (9 A) and coil voltage (24V DC) to your motor's full-load current and control circuit. Ensure the contactor has enough poles (3) and normally open contacts for reversing duty. Verify that surge suppression is handled externally if not integrated.
