SCHNEIDER Supplementary Protector: 25 A Amps, 14kA at 240V AC, Screw Clamp, C60SP - C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERC-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 25 A Amps, 14kA at 240V AC, Screw Clamp, C60SP

The SCHNEIDER IEC Supplementary Protector is a C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 25 A Amps. Part of the C60SP series (MPN M9F22225), it features a Max. AIR Rating of 14kA at 240V…

SKU 3G-OTH-20903

Brand
SCHNEIDER
Item
Supplementary Protector: 25 A Amps, 14kA at 240V AC, Screw Clamp, C60SP
Category
C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9F22225
Series
C60SP
Type
14kA at 240V AC, Screw Clamp, C60SP, C
Curve Type
C
Max. AIR Rating
14kA at 240V AC
AC Voltage Rating
240/415/440V AC
DC Voltage Rating
Not Rated
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a C-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protector rated at 25 A Amps. Part of the C60SP series (MPN M9F22225), it features a Max. AIR Rating of 14kA at 240V AC and an AC Voltage Rating of 240/415/440V AC. The unit uses a Screw Clamp terminal connection and is not rated for DC voltage.

Frequently Asked Questions

What is the SCHNEIDER C60SP supplementary protector used for?

The SCHNEIDER C60SP supplementary protector (M9F22225) protects branch circuits and equipment from overloads and short circuits in industrial control panels, HVAC systems, and machinery. Its C-curve trip characteristic suits moderate inrush loads like motors and transformers. 3G Electric supplies this UL1077-rated device for worldwide industrial applications.

What are the specifications of the SCHNEIDER M9F22225?

The SCHNEIDER M9F22225 is a 25 A, 2-pole C60SP supplementary protector with a C-curve, 14kA interrupting rating at 240V AC, and AC voltage rating of 240/415/440V AC. It uses screw-clamp terminals, mounts on DIN rail, and is not DC-rated. 3G Electric sources this genuine SCHNEIDER part for global delivery.

Where to buy SCHNEIDER M9F22225 supplementary protector worldwide?

3G Electric supplies the SCHNEIDER M9F22225 supplementary protector to customers worldwide. We handle full logistics, customs clearance, and delivery to your facility. As a global industrial solutions provider, we source genuine SCHNEIDER circuit protection components and support procurement teams across 14 industrial departments.

How to install a SCHNEIDER C60SP DIN rail protector?

Install the SCHNEIDER C60SP by snapping it onto a standard 35 mm DIN rail. Ensure the supply is de-energized, then connect phase and load wires to the screw-clamp terminals per the wiring diagram. Torque terminals to manufacturer specifications. 3G Electric provides technical support for proper installation and selection.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.
