SCHNEIDER Supplementary Protector: 1 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp - DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERDC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 1 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector is a 1 A, 1-pole, DC-only rated UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It features a C curve type, a DC voltage rating of 250V DC, a maximum…

SKU 3G-OTH-19528

Brand
SCHNEIDER
Item
Supplementary Protector: 1 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp
Category
DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9U21101
Series
C60H-DC
Type
5kA at 250V DC, Screw Clamp, C60H-DC, C
DC
250V
Curve Type
C
Max. AIR Rating
5kA at 250V DC
AC Voltage Rating
Not Rated
DC Voltage Rating
250V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a 1 A, 1-pole, DC-only rated UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It features a C curve type, a DC voltage rating of 250V DC, a maximum AIR rating of 5kA at 250V DC, and screw clamp terminals. This device is not rated for AC voltage.

Frequently Asked Questions

What is the SCHNEIDER C60H-DC supplementary protector used for?

The SCHNEIDER C60H-DC supplementary protector is used to protect DC circuits from overcurrent and short circuits in industrial control panels, telecommunications, and renewable energy systems. It is a 1-pole, DC-only rated device with a C curve, 1 A rating, and 250V DC voltage rating.

What are the specifications of the SCHNEIDER M9U21101?

The SCHNEIDER M9U21101 is a 1 A, 1-pole DC supplementary protector from the C60H-DC series. It has a DC voltage rating of 250V DC, a maximum AIR rating of 5kA at 250V DC, a C curve type, and screw clamp terminals. It is UL1077 listed and not rated for AC voltage.

Where to buy SCHNEIDER C60H-DC supplementary protectors worldwide?

You can source SCHNEIDER C60H-DC supplementary protectors worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead times on the M9U21101 model.

How to install a SCHNEIDER C60H-DC supplementary protector?

Install the SCHNEIDER C60H-DC supplementary protector by snapping it onto a standard DIN rail. Ensure the DC circuit is de-energized. Connect wires to the screw clamp terminals per the torque specifications in the datasheet. Verify polarity and that the system voltage does not exceed 250V DC.
