SCHNEIDER Supplementary Protector: 2 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp - DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERDC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 2 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 1-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It is rated for 2 A amps at 250V DC with a maximum AIR rating of 5kA at 250V…

SKU 3G-OTH-19548

Brand
SCHNEIDER
Item
Supplementary Protector: 2 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp
Category
DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9U21102
Series
C60H-DC
Type
5kA at 250V DC, Screw Clamp, C60H-DC, C
DC
250V
Curve Type
C
Max. AIR Rating
5kA at 250V DC
AC Voltage Rating
Not Rated
DC Voltage Rating
250V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a DC-only rated, 1-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It is rated for 2 A amps at 250V DC with a maximum AIR rating of 5kA at 250V DC, features a C curve type, and uses screw clamp terminals (MPN M9U21102). This device is not rated for AC voltage.

Frequently Asked Questions

What is the SCHNEIDER C60H-DC supplementary protector used for?

The SCHNEIDER C60H-DC supplementary protector is used for DC-only circuit protection in industrial control panels, solar systems, and battery banks. It safeguards equipment against overcurrent and short circuits with a 2 A rating at 250V DC and a 5kA interrupting capacity.

What are the specifications of the SCHNEIDER M9U21102?

The SCHNEIDER M9U21102 is a 1-pole UL1077 supplementary protector from the C60H-DC series. It is rated for 2 A at 250V DC, has a maximum AIR rating of 5kA at 250V DC, a C curve type, and screw clamp terminals. It is not rated for AC voltage.

Where to buy the SCHNEIDER C60H-DC supplementary protector worldwide?

You can source the SCHNEIDER C60H-DC supplementary protector from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring reliable supply for your DC protection needs.

How to install a SCHNEIDER C60H-DC supplementary protector?

Install the SCHNEIDER C60H-DC supplementary protector by snapping it onto a DIN rail. Connect wires using the screw clamp terminals, ensuring proper torque per manufacturer guidelines. Verify DC polarity and that the system voltage does not exceed 250V DC. Always de-energize before installation.
