SCHNEIDER Supplementary Protector: 16 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp - DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
SCHNEIDERDC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

SCHNEIDER Supplementary Protector: 16 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp

The SCHNEIDER IEC Supplementary Protector is a 16 A, DC-only rated, 1-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It features a C curve type, a maximum AIR rating of 5kA at 250V DC…

SKU 3G-OTH-19631

Brand
SCHNEIDER
Item
Supplementary Protector: 16 A Amps, 250V DC, 5kA at 250V DC, Screw Clamp
Category
DC-Only Rated, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
M9U21116
Series
C60H-DC
Type
5kA at 250V DC, Screw Clamp, C60H-DC, C
DC
250V
Curve Type
C
Max. AIR Rating
5kA at 250V DC
AC Voltage Rating
Not Rated
DC Voltage Rating
250V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER IEC Supplementary Protector is a 16 A, DC-only rated, 1-pole UL1077 DIN rail-mount supplementary protector from the C60H-DC series. It features a C curve type, a maximum AIR rating of 5kA at 250V DC, and a DC voltage rating of 250V DC with screw clamp terminals (MPN M9U21116). This device is not rated for AC voltage applications.

Frequently Asked Questions

What is the SCHNEIDER C60H-DC supplementary protector used for?

The SCHNEIDER C60H-DC supplementary protector (MPN M9U21116) is used for DC circuit protection in industrial control panels, solar arrays, and battery systems. It is a 16 A, 1-pole UL1077 device rated for 250V DC only, with a C curve and 5kA interrupting capacity. It is not rated for AC applications.

What are the specifications of the SCHNEIDER M9U21116?

The SCHNEIDER M9U21116 is a 16 A, 1-pole DC supplementary protector from the C60H-DC series. It has a DC voltage rating of 250V DC, a maximum AIR rating of 5kA at 250V DC, a C curve type, and screw clamp terminals. It is UL1077 listed for DC-only use and is not rated for AC voltage.

Where to buy SCHNEIDER C60H-DC supplementary protectors worldwide?

3G Electric supplies SCHNEIDER C60H-DC supplementary protectors (MPN M9U21116) worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this DC-rated protector.

How to select the right SCHNEIDER supplementary protector for DC circuits?

Select a SCHNEIDER supplementary protector like the C60H-DC (M9U21116) by matching the DC voltage rating (250V DC), current rating (16 A), and interrupting capacity (5kA) to your circuit. Use a C curve for moderate inrush loads. Ensure the device is UL1077 listed and rated for DC-only applications, as this model is not for AC.
