SCHNEIDER Pilot Light Head: 16 mm Panel Mounting Hole Dia, White, Smooth, LED - Pilot-Light Heads
SCHNEIDERPilot-Light Heads

SCHNEIDER Pilot Light Head: 16 mm Panel Mounting Hole Dia, White, Smooth, LED

The SCHNEIDER ELECTRIC Pilot Light Head (SKU 4VW59, MPN ZB6DV1) is a white, smooth pilot-light head with a 16 mm panel mounting hole diameter. It is compatible with the XB5 series and uses an Integral LED Module as…

SKU 3G-OTH-31170

Brand
SCHNEIDER
Item
Pilot Light Head: 16 mm Panel Mounting Hole Dia, White, Smooth, LED
Category
Pilot-Light Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB6DV1
Type
White, Smooth, LED, XB5 Series
Compatible with Series
XB5
Compatible Lamp Module Type
Integral LED Module
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Pilot Light Head (SKU 4VW59, MPN ZB6DV1) is a white, smooth pilot-light head with a 16 mm panel mounting hole diameter. It is compatible with the XB5 series and uses an Integral LED Module as its lamp module type.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1 used for?

The SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1 is used as a visual indicator on industrial control panels. It signals machine status—such as power on, fault, or operation—when paired with an XB5 series base and integral LED module. Common in manufacturing, automation, and process control environments.

What are the specifications of the SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1?

The SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1 has a 16 mm panel mounting hole diameter, white smooth lens, and uses an integral LED module. It is part of the XB5 series. The manufacturer part number is ZB6DV1. It requires a compatible XB5 base and LED module for operation.

Where to buy the SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1 worldwide?

You can source the SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time. We supply genuine SCHNEIDER components.

How to install the SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1?

To install the SCHNEIDER ELECTRIC Pilot Light Head ZB6DV1, mount it into a 16 mm panel hole, then attach the compatible XB5 series base and integral LED module from behind. Secure with the provided retaining ring. Ensure wiring matches the LED module voltage. Follow standard panel installation safety practices.

Used in

Common applications for SCHNEIDER
Motor starting in conveyor systems — Schneider Altistart ATS 22 soft starters (e.g., ATS22D17S6U) reduce inrush current.
Speed control for industrial pumps — Schneider Altivar ATV320 VFDs (e.g., ATV320U55N4W) provide variable flow regulation.
Machine safety interlocking — Schneider XPSUAF13AP safety relays monitor emergency stop circuits on assembly lines.
Panel-mounted control stations — Schneider XB5 flush push buttons (ZB5AA5) serve as start/stop operators in MCCs.
Heavy-duty motor switching — Schneider LC1G150LSEA contactors handle 150 A loads in compressor and crusher applications.
Emergency stop actuation — Schneider 9001K mushroom-head push buttons (9001KR25R) provide red, momentary stop functions.

SCHNEIDER Products

3G Electric supplies SCHNEIDER pilot-light heads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
