SCHNEIDER Pilot Light Head: 30 mm Panel Mounting Hole Dia, Blue, Smooth, LED - Pilot-Light Heads
SCHNEIDERPilot-Light Heads

SCHNEIDER Pilot Light Head: 30 mm Panel Mounting Hole Dia, Blue, Smooth, LED

The SCHNEIDER ELECTRIC Pilot Light Head is a 30 mm panel mounting hole diameter pilot-light head from the XB4 series. It features a blue, smooth lens and is compatible with a Universal LED Module. This component is…

SKU 3G-OTH-30529

Brand
SCHNEIDER
Item
Pilot Light Head: 30 mm Panel Mounting Hole Dia, Blue, Smooth, LED
Category
Pilot-Light Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4FV063
Type
Blue, Smooth, LED, XB4 Series
Compatible with Series
XB4
Compatible Lamp Module Type
Universal LED Module
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Pilot Light Head is a 30 mm panel mounting hole diameter pilot-light head from the XB4 series. It features a blue, smooth lens and is compatible with a Universal LED Module. This component is designed for use with the XB4 series and carries the manufacturer part number ZB4FV063.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063 used for?

The SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063 is a 30 mm panel-mount indicator head from the XB4 series. It provides a blue visual signal when paired with a compatible Universal LED Module, commonly used on industrial control panels, machinery, and automation systems to indicate equipment status.

What are the specifications of the SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063?

The SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063 has a 30 mm panel mounting hole diameter, a blue smooth lens, and is part of the XB4 series. It is compatible with a Universal LED Module and carries the manufacturer part number ZB4FV063. It is designed for use with SCHNEIDER XB4 series components.

Where to buy the SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063 worldwide?

You can source the SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this XB4 series component.

How to install the SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063?

To install the SCHNEIDER ELECTRIC Pilot Light Head ZB4FV063, mount it into a 30 mm panel hole and secure it with the provided retaining ring. Then attach a compatible Universal LED Module (sold separately) to the back of the head. Follow standard electrical safety practices and consult the XB4 series installation guide for wiring details.
