SCHNEIDER Pilot Light Head: 22 mm Panel Mounting Hole Dia, Orange, Smooth - Pilot-Light Heads
SCHNEIDERPilot-Light Heads

SCHNEIDER Pilot Light Head: 22 mm Panel Mounting Hole Dia, Orange, Smooth

The SCHNEIDER ELECTRIC Pilot Light Head is a pilot-light head from the XB4 series, featuring a 22 mm panel mounting hole diameter and an orange, smooth finish. It is compatible with BA9 lamp modules and carries the…

SKU 3G-OTH-30861

Brand
SCHNEIDER
Item
Pilot Light Head: 22 mm Panel Mounting Hole Dia, Orange, Smooth
Category
Pilot-Light Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
ZB4BV05
Type
Orange, Smooth, XB4 Series
Compatible with Series
XB4
Compatible Lamp Module Type
BA9 Lamp Module
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER ELECTRIC Pilot Light Head is a pilot-light head from the XB4 series, featuring a 22 mm panel mounting hole diameter and an orange, smooth finish. It is compatible with BA9 lamp modules and carries the manufacturer part number ZB4BV05.

Frequently Asked Questions

What is the SCHNEIDER ELECTRIC ZB4BV05 pilot light head used for?

The SCHNEIDER ELECTRIC ZB4BV05 is a pilot-light head from the XB4 series used to provide visual indication of machine status in industrial control panels. Its orange, smooth lens signals warnings or active states, and it mounts in a 22 mm panel hole, compatible with BA9 lamp modules.

What are the specifications of the SCHNEIDER ZB4BV05 pilot light head?

The SCHNEIDER ZB4BV05 is an orange, smooth pilot-light head from the XB4 series with a 22 mm panel mounting hole diameter. It is compatible with BA9 lamp modules and carries the manufacturer part number ZB4BV05. It is designed for industrial control and signalling applications.

Where to buy the SCHNEIDER ZB4BV05 pilot light head worldwide?

3G Electric supplies the SCHNEIDER ZB4BV05 pilot light head worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this XB4 series component.

How to install the SCHNEIDER XB4 series pilot light head?

To install the SCHNEIDER XB4 series pilot light head, mount it into a 22 mm panel cutout and secure it with the supplied retaining ring. Ensure the compatible BA9 lamp module is correctly inserted before tightening. Follow standard electrical safety practices and consult the manufacturer's installation guide.
