SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity - IEC Thermal Overload Relays
SCHNEIDERIEC Thermal Overload Relays

SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity

The SCHNEIDER Overload Relay: Thermal Protection (MPN LRD340L) is a 3-pole IEC thermal overload relay with a 30 A – 40 A range, designed for use with TeSys Deca contactors (40 to 65 Amp Models). It features 1NO/1NC…

SKU 3G-OTH-41911

Brand
SCHNEIDER
Item
Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity
Category
IEC Thermal Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LRD340L
Type
1NO/1NC, Phase Loss Sensitivity, 30 A – 40 A
Poles
3
Compatible Contactors
TeSys Deca (40 to 65 Amp Models)
Auxiliary Contact Form
1NO/1NC
Maximum Voltage Rating
690V AC
Phase Loss Sensitivity
Yes
Thermal Units Required
None (Relay Includes Integrated Bimetallic Elements)
Terminal Connection Type
Screw Clamp Terminals
Compatible Contactor Series
TeSys Deca
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Overload Relay: Thermal Protection (MPN LRD340L) is a 3-pole IEC thermal overload relay with a 30 A – 40 A range, designed for use with TeSys Deca contactors (40 to 65 Amp Models). It features 1NO/1NC auxiliary contacts, screw clamp terminals, a maximum voltage rating of 690V AC, and phase loss sensitivity. The relay includes integrated bimetallic elements, so no separate thermal units are required.

Frequently Asked Questions

What is the SCHNEIDER LRD340L overload relay used for?

The SCHNEIDER LRD340L is a 3-pole IEC thermal overload relay used to protect motors from overload and phase loss. It is designed for use with TeSys Deca contactors (40 to 65 Amp models) in industrial motor control applications, providing reliable thermal protection via integrated bimetallic elements.

What are the specifications of the SCHNEIDER LRD340L overload relay?

The SCHNEIDER LRD340L has a 30 A – 40 A range, 1NO/1NC auxiliary contacts, screw clamp terminals, and a maximum voltage rating of 690V AC. It includes phase loss sensitivity and integrated bimetallic elements, so no separate thermal units are required. It is compatible with TeSys Deca contactors (40 to 65 Amp models).

Where to buy the SCHNEIDER LRD340L overload relay worldwide?

You can source the SCHNEIDER LRD340L overload relay through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine SCHNEIDER components for industrial motor protection.

How to select the correct SCHNEIDER overload relay for a motor?

To select the correct SCHNEIDER overload relay, match the relay's current range (e.g., 30 A – 40 A for LRD340L) to the motor's full-load current. Ensure compatibility with your contactor series (TeSys Deca for this model) and verify voltage rating (690V AC). The LRD340L includes phase loss sensitivity and integrated bimetallic elements for direct installation.
