SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity - IEC Thermal Overload Relays
SCHNEIDERIEC Thermal Overload Relays

SCHNEIDER Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity

The SCHNEIDER Overload Relay: Thermal Protection (SKU 6KYC5, MPN LRD332) is an IEC thermal overload relay with three poles and a 23 A – 32 A range. It features 1NO/1NC auxiliary contacts, a maximum voltage rating of…

SKU 3G-OTH-41534

Brand
SCHNEIDER
Item
Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity
Category
IEC Thermal Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LRD332
Type
1NO/1NC, Phase Loss Sensitivity, 23 A – 32 A
Poles
3
Compatible Contactors
TeSys Deca (40 to 65 Amp Models)
Auxiliary Contact Form
1NO/1NC
Maximum Voltage Rating
690V AC
Phase Loss Sensitivity
Yes
Thermal Units Required
None (Relay Includes Integrated Bimetallic Elements)
Terminal Connection Type
Screw Clamp Terminals
Compatible Contactor Series
TeSys Deca
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Overload Relay: Thermal Protection (SKU 6KYC5, MPN LRD332) is an IEC thermal overload relay with three poles and a 23 A – 32 A range. It features 1NO/1NC auxiliary contacts, a maximum voltage rating of 690V AC, and phase loss sensitivity. The relay includes integrated bimetallic elements, uses screw clamp terminals, and is compatible with TeSys Deca contactors (40 to 65 Amp models).

Frequently Asked Questions

What is the SCHNEIDER LRD332 overload relay used for?

The SCHNEIDER LRD332 is an IEC thermal overload relay that protects three-phase motors from overcurrent and phase loss. It is used in industrial motor control applications, typically paired with TeSys Deca contactors (40 to 65 Amp models) to safeguard equipment in manufacturing, HVAC, and pumping systems.

What are the specifications of the SCHNEIDER LRD332 overload relay?

The SCHNEIDER LRD332 is a three-pole thermal overload relay with a 23 A – 32 A range, 1NO/1NC auxiliary contacts, and a maximum voltage rating of 690V AC. It includes integrated bimetallic elements, phase loss sensitivity, and screw clamp terminals. It is compatible with TeSys Deca contactors (40 to 65 Amp models).

Where to buy the SCHNEIDER LRD332 overload relay worldwide?

You can source the SCHNEIDER LRD332 overload relay through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine SCHNEIDER components for motor protection applications.

How to select the correct SCHNEIDER overload relay for a motor?

To select the correct SCHNEIDER overload relay, match the relay's current range (e.g., 23 A – 32 A for the LRD332) to the motor's full-load amperage. Ensure the relay is compatible with your contactor series, such as TeSys Deca. Verify phase loss sensitivity is needed for your application. Always consult the motor nameplate and manufacturer guidelines.
