Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A - Reversing Starters with Electronic Overloads
SiemensReversing Starters with Electronic Overloads

Siemens Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A

The SIEMENS NEMA Magnetic Motor Starter is a reversing starter with electronic overloads, featuring three poles, NEMA Size 1, and a 27 A rating. It operates with a 380-440/440-480V AC coil voltage and includes a…

SKU 3G-OTH-43466

Brand
Siemens
Item
Magnetic Motor Starter: Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
22DUC32AH
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
480V
Coil Voltage
380-440/440-480V AC
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Terminals
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIEMENS NEMA Magnetic Motor Starter is a reversing starter with electronic overloads, featuring three poles, NEMA Size 1, and a 27 A rating. It operates with a 380-440/440-480V AC coil voltage and includes a pilot light, 1NO auxiliary contact, and screw terminals. No thermal units are required as the overload protection is electronic.

Frequently Asked Questions

What is the SIEMENS NEMA Magnetic Motor Starter 22DUC32AH used for?

This reversing starter with electronic overloads controls three-phase motors up to 27 A, enabling forward/reverse operation in industrial machinery such as conveyors, hoists, and pumps. It is suitable for NEMA Size 1 applications requiring reliable motor protection and pilot-light signaling.

What are the specifications of the SIEMENS 22DUC32AH reversing starter?

The SIEMENS 22DUC32AH is a NEMA Size 1, three-pole reversing starter rated 27 A with a 380-440/440-480V AC coil voltage. It includes one normally-open auxiliary contact, screw terminals, a pilot light, and electronic overload protection. No thermal units are required.

Where to buy the SIEMENS 22DUC32AH reversing starter worldwide?

3G Electric supplies the SIEMENS 22DUC32AH reversing starter worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this Siemens-brand component to any country.

How to select the correct NEMA reversing starter for a motor?

Match the starter's NEMA size and current rating to the motor's full-load amps and voltage. For the SIEMENS 22DUC32AH, verify the motor is three-phase, 27 A or less, and the coil voltage matches your control circuit (380-440/440-480V AC). Electronic overloads eliminate the need for separate thermal units.

Used in

Common applications for Siemens
District cooling plants — LME73 + RWF55 for condenser-water modulation
Inflight catering and food-processing steam boilers — LMG22 with SQN90 air-fuel cross-damper
Hospital steam-plant redundancy — LME41 with QRA2 UV flame detection for dual-fuel boilers
Semiconductor fab process heat — LME23 and SKP55 gas valves on hot-oil heater skids
Container-terminal reefer-deck heating — LMG22 retrofit onto legacy burner racks

Siemens Products

3G Electric supplies Siemens reversing starters with electronic overloads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
