Siemens Molded Case Circuit Breaker: 45 A Amps, 10kA at 240V AC, Fixed, Load Side Lug - ED-Frame Siemens Molded Case Circuit Breakers
SiemensED-Frame Siemens Molded Case Circuit Breakers

Siemens Molded Case Circuit Breaker: 45 A Amps, 10kA at 240V AC, Fixed, Load Side Lug

The Siemens ED-Frame Molded Case Circuit Breaker (SKU 6FMZ4, MPN ED22B045) is a 45 A amp, ED2-series device with a maximum AIR rating of 10kA at 240V AC. It features a fixed instantaneous trip, load-side lug terminal…

SKU 3G-OTH-21894

Brand
Siemens
Item
Molded Case Circuit Breaker: 45 A Amps, 10kA at 240V AC, Fixed, Load Side Lug
Category
ED-Frame Siemens Molded Case Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Siemens
Manufacturer Part Number
ED22B045
Series
ED2
Type
10kA at 240V AC, Fixed, Load Side Lug, Any, ED2
Max. AIR Rating
10kA at 240V AC
Phase Connection
Any
Instantaneous Trip
Fixed
Terminal Connection
Load Side Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Siemens Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Siemens ED-Frame Molded Case Circuit Breaker (SKU 6FMZ4, MPN ED22B045) is a 45 A amp, ED2-series device with a maximum AIR rating of 10kA at 240V AC. It features a fixed instantaneous trip, load-side lug terminal connection, and supports any phase connection.

Frequently Asked Questions

What is the Siemens ED22B045 molded case circuit breaker used for?

The Siemens ED22B045 is a 45 A molded case circuit breaker used for overcurrent protection in industrial and commercial electrical distribution panels. It is suitable for branch circuits, feeder protection, and motor control centers where a fixed instantaneous trip and load-side lug connections are required.

What are the specifications of the Siemens ED22B045 circuit breaker?

The Siemens ED22B045 is a 45 A, ED2-series molded case circuit breaker with a maximum AIR rating of 10kA at 240V AC. It features a fixed instantaneous trip, load-side lug terminal connection, and supports any phase connection. The manufacturer part number is ED22B045.

Where to buy the Siemens ED22B045 circuit breaker worldwide?

You can source the Siemens ED22B045 circuit breaker through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this ED2-series breaker.

How to select the correct Siemens ED2 molded case circuit breaker?

To select the correct Siemens ED2 breaker, verify the amp rating (45 A), maximum AIR rating (10kA at 240V AC), and terminal connection type (load-side lug). Ensure the fixed instantaneous trip matches your application. Consult a licensed electrician for proper coordination with upstream protection devices.
