SIMPSON ELECTRIC External Portable Shunt: External Portable Shunt, 5 A DC, 50 mV DC Volt Drop - External Portable Shunts
SIMPSON ELECTRICExternal Portable Shunts

SIMPSON ELECTRIC External Portable Shunt: External Portable Shunt, 5 A DC, 50 mV DC Volt Drop

The SIMPSON ELECTRIC External Portable Shunt (model 06703) is a 5 A DC shunt with a 50 mV DC voltage drop, designed for use with analog panel meters. It includes 5 ft leads for portable connection.

SKU 3G-OTH-28916

Brand
SIMPSON ELECTRIC
Item
External Portable Shunt: External Portable Shunt, 5 A DC, 50 mV DC Volt Drop
Category
External Portable Shunts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SIMPSON ELECTRIC
Manufacturer Part Number
06703
Type
50 mV DC Volt Drop, 06703
DC
5 A
Current
5 A DC
Includes
5 ft Leads
Product Type
External Portable Shunt
Compatible Product Type
Analog Panel Meters
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SIMPSON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIMPSON ELECTRIC External Portable Shunt (model 06703) is a 5 A DC shunt with a 50 mV DC voltage drop, designed for use with analog panel meters. It includes 5 ft leads for portable connection.

Frequently Asked Questions

What is the SIMPSON ELECTRIC External Portable Shunt used for?

The SIMPSON ELECTRIC External Portable Shunt (model 06703) is used to extend the current measurement range of analog panel meters. It is commonly applied in industrial electrical testing, maintenance, and troubleshooting where portable DC current measurement up to 5 A is required.

What are the specifications of the SIMPSON ELECTRIC 06703 shunt?

The SIMPSON ELECTRIC 06703 is a 5 A DC external portable shunt with a 50 mV DC voltage drop. It includes 5 ft leads for flexible connection and is designed for use with analog panel meters. The manufacturer part number is 06703.

Where to buy the SIMPSON ELECTRIC 06703 shunt worldwide?

3G Electric supplies the SIMPSON ELECTRIC 06703 external portable shunt to customers worldwide. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct external portable shunt for analog panel meters?

Select a shunt with a current rating matching your meter's full-scale range and a voltage drop (typically 50 mV or 100 mV) that matches the meter's input. The SIMPSON ELECTRIC 06703 is a 5 A DC, 50 mV shunt, ideal for portable use with compatible analog panel meters.
