SIMPSON ELECTRIC External Portable Shunt: External Portable Shunt, 25 A DC - External Portable Shunts
SIMPSON ELECTRICExternal Portable Shunts

SIMPSON ELECTRIC External Portable Shunt: External Portable Shunt, 25 A DC

The SIMPSON ELECTRIC External Portable Shunt (MPN 06707) is a 25 A DC shunt with a 50 mV DC volt drop, designed for use with compatible digital panel meters. It includes 5 ft leads for portable measurement applications.

SKU 3G-OTH-28909

Brand
SIMPSON ELECTRIC
Item
External Portable Shunt: External Portable Shunt, 25 A DC
Category
External Portable Shunts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SIMPSON ELECTRIC
Manufacturer Part Number
06707
Type
50 mV DC Volt Drop
DC
25 A
Current
25 A DC
Includes
5 ft Leads
Product Type
External Portable Shunt
Compatible Product Type
Digital Panel Meters
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SIMPSON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SIMPSON ELECTRIC External Portable Shunt (MPN 06707) is a 25 A DC shunt with a 50 mV DC volt drop, designed for use with compatible digital panel meters. It includes 5 ft leads for portable measurement applications.

Frequently Asked Questions

What is the SIMPSON ELECTRIC External Portable Shunt used for?

The SIMPSON ELECTRIC External Portable Shunt (MPN 06707) is used to measure DC current by producing a 50 mV DC voltage drop at 25 A DC. It connects to compatible digital panel meters for portable current measurement in industrial electrical testing and monitoring applications.

What are the specifications of the SIMPSON ELECTRIC External Portable Shunt?

The SIMPSON ELECTRIC External Portable Shunt (MPN 06707) is rated for 25 A DC with a 50 mV DC volt drop. It includes 5 ft leads and is designed for use with compatible digital panel meters. The shunt is portable and external, suitable for field measurements.

Where to buy the SIMPSON ELECTRIC External Portable Shunt worldwide?

3G Electric supplies the SIMPSON ELECTRIC External Portable Shunt (MPN 06707) worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the SIMPSON ELECTRIC External Portable Shunt?

To install the SIMPSON ELECTRIC External Portable Shunt, connect the 5 ft leads between the shunt and a compatible digital panel meter. Ensure the shunt is placed in series with the DC load. Follow standard electrical safety practices and verify connections before energizing the circuit.

Used in

Common applications for SIMPSON ELECTRIC
Industrial control panels — SIMPSON ELECTRIC A201 multi-function digital panel meters for monitoring AC voltage and current with RS-485 communication.
Switchgear monitoring — SIMPSON ELECTRIC switchboard shunts (e.g., 06508) for DC current measurement in high-current distribution systems.
Portable test equipment — SIMPSON ELECTRIC external portable shunts (e.g., 06713) for field measurement of DC currents up to 200 A.
Temperature monitoring in HVAC — SIMPSON ELECTRIC Hawk 3 temperature digital panel meters for displaying RTD or thermocouple readings.
Power quality analysis — SIMPSON ELECTRIC Mini-Max DC voltage digital panel meters for measuring battery bank voltages in UPS systems.
Retrofit current monitoring — SIMPSON ELECTRIC split core current transformers (e.g., 37035) for non-invasive AC current sensing in existing bus bars.

SIMPSON ELECTRIC Products

3G Electric supplies SIMPSON ELECTRIC external portable shunts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
