SKF Rotary Shaft Seal: 1 Lip w/Spring, HMS4, Nitrile, 1.614 in ID, 2.323 in OD - Single-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores
SKFSingle-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores

SKF Rotary Shaft Seal: 1 Lip w/Spring, HMS4, Nitrile, 1.614 in ID, 2.323 in OD

The SKF Rotary Shaft Seal is a single-lip oil seal with a rubber-enclosed case for rough bores, featuring an HMS4 seal design. This inch-system seal has a 1.614 in inside diameter, 2.323 in outside diameter, and…

SKU 3G-OTH-123464

Brand
SKF
Item
Rotary Shaft Seal: 1 Lip w/Spring, HMS4, Nitrile, 1.614 in ID, 2.323 in OD
Category
Single-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SKF
Manufacturer Part Number
16023
Type
HMS4, Nitrile
OD
2.323 in
Wd
0.315 in
ID
1.614 in
Seal Design
HMS4
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SKF Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SKF Rotary Shaft Seal is a single-lip oil seal with a rubber-enclosed case for rough bores, featuring an HMS4 seal design. This inch-system seal has a 1.614 in inside diameter, 2.323 in outside diameter, and 0.315 in width, and is made of nitrile material (MPN 16023). It includes a spring-loaded lip for effective sealing in industrial equipment applications.

Frequently Asked Questions

What is the SKF Rotary Shaft Seal 16023 used for?

The SKF Rotary Shaft Seal 16023 is a single-lip oil seal with a rubber-enclosed case designed for rough bores. It seals rotating shafts in industrial equipment such as pumps, gearboxes, and motors, preventing lubricant leakage and contaminant ingress. Its spring-loaded nitrile lip ensures reliable sealing in demanding applications.

What are the specifications of the SKF 16023 seal?

The SKF 16023 seal has a 1.614 in inside diameter, 2.323 in outside diameter, and 0.315 in width. It features an HMS4 design with a nitrile lip and a spring. This inch-system seal is a single-lip oil seal with a rubber-enclosed case for rough bores, manufactured by SKF under MPN 16023.

Where to buy SKF rotary shaft seals worldwide?

3G Electric supplies SKF rotary shaft seals like the 16023 to customers worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance for international delivery. Contact us to source this seal or other SKF components for your maintenance or production needs.

How to install an SKF HMS4 rotary shaft seal?

To install an SKF HMS4 seal, ensure the housing bore is clean and free of burrs. Lubricate the seal lip and shaft with compatible oil. Press the seal evenly into the bore using a suitable driver, avoiding damage to the rubber case. Verify the seal is seated squarely and the spring is properly positioned.
