SKF Rotary Shaft Seal: 1 Lip w/Spring, HMS4, Nitrile, 20 mm ID, 28 mm OD - Single-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores
SKFSingle-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores

SKF Rotary Shaft Seal: 1 Lip w/Spring, HMS4, Nitrile, 20 mm ID, 28 mm OD

The SKF Rotary Shaft Seal is a single-lip oil seal with a rubber-enclosed case for rough bores, featuring an HMS4 seal design. This metric seal has a 20 mm inner diameter, 28 mm outer diameter, and 6 mm width…

SKU 3G-OTH-122659

Brand
SKF
Item
Rotary Shaft Seal: 1 Lip w/Spring, HMS4, Nitrile, 20 mm ID, 28 mm OD
Category
Single-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SKF
Manufacturer Part Number
20X28X6 HMS4 R
Type
HMS4, Nitrile
OD
28 mm
Wd
6 mm
ID
20 mm
Seal Design
HMS4
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SKF Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SKF Rotary Shaft Seal is a single-lip oil seal with a rubber-enclosed case for rough bores, featuring an HMS4 seal design. This metric seal has a 20 mm inner diameter, 28 mm outer diameter, and 6 mm width, constructed from nitrile material with a spring. It is manufactured by SKF under part number 20X28X6 HMS4 R.

Frequently Asked Questions

What is the SKF 20X28X6 HMS4 R rotary shaft seal used for?

The SKF 20X28X6 HMS4 R is a single-lip oil seal designed to retain lubricants and exclude contaminants in rotating shaft applications. It is commonly used in gearboxes, pumps, and motors where a 20 mm shaft and 28 mm housing bore require a reliable seal in rough bore conditions.

What are the specifications of the SKF 20X28X6 HMS4 R seal?

This SKF rotary shaft seal has a 20 mm inner diameter, 28 mm outer diameter, and 6 mm width. It features an HMS4 seal design with a nitrile rubber-enclosed case and a spring. The system of measurement is metric, and the manufacturer part number is 20X28X6 HMS4 R.

Where to buy the SKF 20X28X6 HMS4 R seal worldwide?

You can source the SKF 20X28X6 HMS4 R seal through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this SKF part.

How to install the SKF HMS4 rotary shaft seal?

To install the SKF HMS4 seal, ensure the shaft and housing bore are clean and free of burrs. Apply a thin lubricant to the seal lip and shaft. Use a seal installation tool to press the seal evenly into the bore, avoiding damage to the nitrile lip. Never hammer directly on the seal.
